The Waxing Moon of Spring




Four-Day-Old Moon with EarthshineSpring is the season for Earthshine on the waxing Moon.

April 8 was the perfect night for capturing the waxing crescent Moon illuminated both by the Sun and by the Earth.

The phase was a 4-day-old Moon, old enough to be high in the sky, but young enough – i.e. a thin enough crescent – that its bright side didn’t wash out the dark side!

In the lead photo at top, and even in the single-exposure image below taken earlier in a brighter sky, you can see the night side of the Moon faintly glowing a deep blue, and brighter than the background twilight sky.

Four-Day-Old Moon in Blue Twilight
The 4-day-old waxing crescent Moon on April 8, 2019 in a single exposure when the Moon was still in the bright blue twilight. Even so, the faint Earthshine is just becoming visible. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a single 1/8-second exposure.

This, too, is from sunlight, but light that has bounced off the Earth first to then light up the night side of the Moon.

If you were standing on the lunar surface on the night side, the Sun would be below the horizon but your sky would contain a brilliant blue and almost Full Earth lighting your night, much as the Moon lights our Earthly nights. However, Earth is some 80 times brighter in the Moon’s sky than even the Full Moon is in our sky.

Four-Day-Old Moon with Earthshine
The 4-day-old waxing crescent Moon on April 8, 2019 in a blend of short and long exposures to bring out the faint Earthshine on the dark side of the Moon and deep blue twilight sky while retaining details in the bright sunlit crescent. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a blend of 7 exposures from 1/30 second to 2 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop.



Unlike the single image, the lead image, repeated just above, is a multi-exposure blend (using luminosity masks), to bring out the faint Earthshine and deep blue sky, while retaining details in the bright crescent.

Once the sky gets dark enough to see Earthshine well, no single exposure can record the full range in brightness on both the day and night sides of the Moon.



Waxing Moon, Mars and the Taurus Clusters
The 4-day-old waxing crescent Moon on April 8, 2019 with it below Mars (at top) and the star clusters, the Hyades (at left, with reddish Aldebaran) and Pleiades (at right) in Taurus, and set into the deep blue evening twilight. This is with the 135mm Canon telephoto at f/2.8 with the Canon 6D at ISO 400, in a blend of 7 exposures from 1/4 second to 8 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop, to prevent the Moon from being too overexposed while retaining the stars and blue sky. The camera was tracking the sky.

April 8 was a great night for lunar fans as the crescent Moon also appeared between the two bright star clusters in Taurus, the Hyades and Pleiades, and below reddish Mars.

It was a fine gathering of celestial sights, captured above with a telephoto lens.

April 8 Sky

This show the chart I used to plan the framing, created with StarryNight™ software and showing the field of the 135mm lens I used.

The chart also shows why spring is best for the waxing Moon. It is at this time of year that the ecliptic – the green line – swings highest into the evening sky, taking the Moon with it, placing it high in the west above obscuring haze.

That makes it easier to see and shoot the subtle Earthshine. And to see sharp details on the Moon.

After the sky got darker I shot the crescent Moon in a short exposure to capture just the bright crescent, included above in two versions – plain and with labels attached marking the major features visible on a 4-day Moon.

If you missed “Earthshine night” this month, mark May 7 and 8 on your calendar for next month’s opportunities.

Clear skies!

— Alan, April 9, 2019 / © 2019 Alan Dyer / AmazingSky.com



Dinosaur Park in the Dark


Winter Sky Setting in Twilight at Dinosaur Park

There’s a slogan used in the U.S. National Parks that “half the Park is after dark.” It is certainly true at Dinosaur Provincial Park in Alberta.

Last Friday night, March 29, I spent the evening at one of my favourite nightscape sites, Dinosaur Provincial Park, about an hour’s drive east of my home. It was one of those magical nights – clear, mild, dry, and no mosquitoes! Yet!

I wanted to shoot Orion and the photogenic winter sky setting into the evening twilight over the Badlands landscape. This was the last moonless weekend to do so.

I shot some individual images (such as above) and also multi-panel panoramas, created by shooting a series of overlapping images at equal spacings, then stitching them later at the computer.

Winter Sky Setting at Dinosaur Park Panorama
This is a 240° panorama stitched from 17 segments, all with the 24mm Sigma Art lens and Nikon D750 in portrait orientation, each segment 20 seconds at f/1.4 and ISO 3200. Stitched with Adobe Camera Raw.

There’s a narrow window of time between twilight and full darkness when the Milky Way shows up well but the western sky still has a lingering blue glow. This window occurs after the normal “blue hour” favoured by photographers.

The panorama above shows the arch of the winter Milky Way but also the towering band of the Zodiacal Light rising out of the twilight and distant yellow glow of Calgary. Zodiacal Light is sunlight scattering off meteoric and cometary dust orbiting in the inner solar system, so this is a phenomenon in space not in our atmosphere. However, the narrow streak is an aircraft contrail.

Spring Sky Panorama at Dinosaur Park
A 360° panorama of the spring sky over the Badlands of Dinosaur Provincial Park, Alberta. This is a panorama of 12 segments taken with the 14mm Sigma Art lens and Nikon D750 in portrait orientation, all for 30 seconds at f/2.8 and ISO 4000. Taken at 30° spacings. Stitched with PTGui.

Later that night, when the sky was fully dark I shot this complete panorama showing not only the Milky Way and Zodiacal Light to the west, but also the faint arc of the Zodiacal Band continuing on from the pyramid-shaped Zodiacal Light over into the east, where it brightens into the subtle glow of Gegenschein. This is caused by sunlight reflecting off interplanetary dust particles in the direction opposite the Sun.

Both the Band and Gegenschein were visible to the naked eye, but only if you knew what to look for, and have a very dark sky.

The Winter Stars and Zodiacal Light at Dinosaur Park
This is a panorama stitched from 3 segments, all with the 24mm Sigma Art lens and Nikon D750, for 20 seconds at f/2.2 and ISO 4000. Stitched with Adobe Camera Raw.

A closeup shows the Zodiacal Light in the west as the subtle blue glow tapering toward the top as it meets the Milky Way.

It takes a dark site to see these subtle glows. Dinosaur Park is not an official Dark Sky Preserve but certainly deserves to be. Now if we could only get Calgary, Brooks and Bassano to turn down and shield their lights!

Spring Sky RIsing at Dinosaur Park Panorama
A 180° panorama of the spring sky and constellations rising in the east over the Badlands of Dinosaur Provincial Park, Alberta on March 29, 2019. This is a stitch of 6 segments, each with the 14mm Sigma Art lens and Nikon D750 in portrait mode, each 30 seconds at f/2.8 and ISO 4000. Stitched with PTGui.

A closeup facing the other way, to the east, shows the area of sky opposite the Milky Way, in the spring sky. The familiar Big Dipper, now high our spring sky, is at top with its handle pointing down to Arcturus and Spica (just rising above the horizon) – remember to “arc to Arcturus, and speed on to Spica.”

Leo is at right of centre, flanked by the Beehive and Coma Berenices star clusters.

Polaris is at left — however, the distortion introduced by the panorama stitching at high altitudes stretches out the sky at the top of the frame, so the Dipper’s Pointer stars do not point in a straight line to Polaris.

The faint Zodiacal Band is visible at right, brightening toward the horizon in the Gegenschein.

I shoot images like these for use as illustrations in future eBook projects about stargazing and the wonders of the night sky. Several are in the works!

Clear skies!

— Alan, April 1, 2019 / © 2019 Alan Dyer / AmazingSky.com



Touring the Wonders of the Winter Sky


The Wonders of the Winter Sky

I present a tour of the deep-sky wonders of the winter sky.

While some might think the Milky Way is only a summer sight, the winter Milky Way is well worth a look!

In January and February we are looking outward from our location in the Milky Way, toward the Orion Spur, the minor spiral arm we live in. In it, and in the major Perseus Arm that lies beyond, lie hotbeds of star formation.

Artist's impression of the Milky Way (updated - annotated)
Courtesy European Southern Observatory

These star forming areas create a panorama of star clusters and glowing nebulas along the winter Milky Way and surrounding the constellation of Orion. The montage above shows the best of the deep-sky sights at this time or year.

(And yes, for southern hemisphere viewers I know this is your summer sky! But for us northerners, Orion is forever associated with frosty winter nights.)

The closeups below are all with a 200mm telephoto lens providing a field of view similar to that of binoculars. However, most of these nebulas are photographic targets only.


The Belt and Sword of Orion

The Belt and Sword of Orion with Barnard's Loop
This is a stack of 16 x 2- to 3-minute exposures with the filter-modified Canon 5D MkII at ISO 800 to 1250 and 200mm Canon L-Series lens at f/2.8. Taken with the Fornax Lightrack tracker as part of testing. Taken from home on January 8, 2019 during a clear couple of hours between passing haze and cloud.

This is the heart of the star formation activity, in the centre of Orion.

The bright Orion Nebula (or Messier 42 and 43) at bottom in Orion’s Sword is obvious in binoculars and glorious in a small telescope.

The Horsehead Nebula above centre and just below Orion’s Belt is famous but is a tough target to see through even a large telescope.

Barnard’s Loop at left is a wave of nebulosity being blown out of the Orion area by strong stellar winds. Any sighting of this object by eye is considered a feat of observing skill!


The Rosette Nebula and Area

Rosette and Christmas Tree Cluster with 200mm
The area of the Rosette Nebula (bottom) and Christmas Tree Cluster (top) in Monoceros with the Fornax Lightrack tracker and 200mm lens and filter modified Canon 5D MkII. This is a stack of 10 x 3 minute exposures at ISO 800.

The small cluster of hot young stars inside the Rosette Nebula is blowing a hole in the nebula giving it its Rosette name. Above is a loose star cluster called the Christmas Tree, surrounded by more faint nebulosity that includes the tiny Cone Nebula.


Gemini Clusters and Nebulas

The Clusters and Nebulas of Gemini
This is a stack of 10 x 3-minute exposures with the filter-modified Canon 5D MkII at ISO 800 and 200mm Canon L-Series lens at f/2.8. Some light haze passing through in some exposures added the natural star glows. I left those in as part of the stack to add the glows. Taken with the Fornax Lightrack tracker as part of testing. Taken from home on a rare fine and mild winter night, January 4, 2019.

This field of clusters and nebulosity is above Orion in Gemini, with Messier 35 the main open star cluster here at top. Below M35 is the tiny star cluster NGC 2158. The nebulosity at left between Mu and Eta Geminorum is IC 443, a remnant of a supernova explosion, and is aka the Jellyfish Nebula. The nebula at bottom is IC 2174, just over the border in Orion and aka the Monkeyhead Nebula.


Auriga Clusters and Nebulas

The Clusters and Nebulas of Auriga
This is a stack of 5 x 3-minute exposures with the filter-modified Canon 5D MkII at ISO 800 and 200mm Canon L-Series lens at f/2.8. Taken with the Fornax Lightrack tracker as part of testing. Diffraction spikes added with Astronomy Tools actions. Taken from home on January 4, 2019.

Above Gemini and Orion lies Auriga, with its rich field of clusters and nebulosity, with — from left to right — Messier 37, Messier 36, and Messier 38, as the main open star clusters here. Below M38 is NGC 1907. The nebulosity at right is IC 410 and IC 405, the Flaming Star Nebula.

In between them is the colourful asterism known as the Little Fish. Messier 38 is also known as the Starfish Cluster while Messier 36 is called the Pinwheel Cluster. The bright red nebula at top is Sharpless 2-235. The little nebulas at centre are NGC 1931 and IC 417.


The California Nebula

The California Nebula in Perseus
This is a stack of 5 x 3-minute exposures with the filter-modified Canon 5D MkII at ISO 800 and 200mm Canon L-Series lens at f/2.8. An additional exposure taken through the Kenko Softon A filter is layered in to add the star glows to bring out their colours. Taken with the Fornax Lightrack tracker. Taken from home on a rare fine and mild winter night, January 4, 2019.

Now we enter Perseus, more an autumn constellation but well up through most of the winter months. It contains the aptly named California Nebula, NGC 1499, at top left, with the bright star Zeta Persei. at bottom A small region of reflection nebulosity, IC 348, surrounds the star Atik, or Omicron Persei, at bottom right. The star just below NGC 1499 is Menkib, or Xi Persei, and is likely energizing the nebula.


The Pleiades, or Seven Sisters

Pleiades M45 with 200mm Lens
The Pleiades with the Fornax Lightrack tracker and 200mm lens + Canon 5D MkII in a stack of 10 x 3 minute exposures at ISO 800.

Obvious to the eye and central to the sky lore of many cultures is the Pleiades, aka the Seven Sisters, in Taurus the bull. It is also called Messier 45.

This is a newly formed cluster of hundreds of stars, passing through a dusty region of the Milky Way, which adds the fuzzy glows around the stars — an example of a reflection nebula, glowing blue as it reflects the blue light of the young stars.


The Hyades

The Hyades Star Cluster with NGC 1647 in Taurus
This is a stack of 5 x 2-minute exposures with the Canon 5D MkII at ISO 800 and 200mm Canon L-Series lens at f/2.8. An additional exposure taken through the Kenko Softon A filter is layered in to add the star glows to bring out their colours. Taken with the Fornax Lightrack tracker. Diffraction spikes added with Astronomy Tools actions for artistic effect.

Below the Pleiades in Taurus lies the larger Hyades star cluster. The V-shaped cluster stars are all moving together and lie about 150 light years away. Bright yellow Aldebaran, the eye of Taurus, is an intruder and lies at only half that distance, so is not a member of Hyades but is a more nearby star. The smaller, more distant star cluster NGC 1647 appears at left.


Seagull Nebula

Seagull Nebula and Sirius with 200mm
This is a stack of 10 x 3 minute exposures at ISO 800 (with the filter-modified Canon 5D MkII and Canon 200mm lens at f/2.8). The rings of colour around Sirius are an artifact of the sensor filter, I think!

Low in my northern winter sky is the brightest star in the sky of any season, Sirius. Just above and to the east of Sirius lies the Seagull Nebula (at top left), also called IC 2177, on the Canis Major-Monoceros border. Like many of these nebulas. the Seagull is too faint to easily see even with a telescope, but shows up well in photographs.


Lambda Orionis Nebula

Lambda Orionis Nebula with 200mm
With the Fornax Lightrack tracker and 200mm lens and filter-modified Canon 5D MkII. A stack of 10 x 3 minute exposures at ISO 800 with the filter-modified Canon 5D MkII and Canon 200mm lens at f/2.8.

This is the head of Orion, with the red supergiant star Betelgeuse at bottom left and the blue giant star Bellatrix right at bottom right. The brightest star at top is Meissa or Lambda Orionis, and is surrounded by a large and very faint area of hydrogen nebulosity. The open cluster around Meissa is catalogued as Collinder 69.

While the winter Milky Way might not look as bright and spectacular as the summer Milky Way of Sagittarius and Scorpius, it does contains a wealth of wonders that are treats for the eye and telescope … and for the camera.

PS.: The techniques for taking and processing images like these form the content of our new Deep Sky with Your DSLR video course now being promoted on KickStarter until the end of February, and available for purchase once it is published later this spring.

See my previous blog post for details.  Thanks and clear skies!

— Alan, February 17, 2019 / © 2019 Alan Dyer / AmazingSky.com



Moonlight in the Badlands


Stars over Sedimentary Layers

Clear nights and a waxing Moon made for great opportunities to shoot the Badlands under moonlight.

This has not been a great spring. Only now is the last of the snow melting here in Alberta.

But some mild and clear nights this week with the waxing gibbous Moon allowed me to head to the Red Deer River valley near where I live in Alberta for some moonlit nightscapes.



Big Dipper over the Badlands

Here’s the Big Dipper high overhead as it is in spring pointing down to Polaris.

I shot this and some other images in this gallery with the new Sony a7III mirrorless camera. A full test of its astrophoto abilities is in the works.

Jupiter Rising over Red Deer River Badlands

This is Jupiter rising, with the Moon lighting the sky, and illuminating the landscape. Moonlight is the same colour as sunlight, just much fainter. So while this might look like a daytime scene, it isn’t.

Venus in Twilight at the Hoodoos

This is Venus setting in the evening twilight at the Hoodoos on Highway 10 near Drumheller. The winter stars are setting into the west, to disappear for a few months.

Venus, Pleiades and Hyades in Twilight

Here’s Venus in closeup, passing between the Hyades and Pleiades star clusters in Taurus, low in the twilight over the scenic Horsethief Canyon area of the Red Deer River.

While Venus is climbing higher into our evening sky this spring, the Pleiades, Hyades and all the winter stars are fast disappearing from view.

We say goodbye to winter, and not a moment too soon!

— Alan, April 28, 2018 / © 2018 Alan Dyer / AmazingSky.com



Farewell Winter Sky


Panorama of the Winter Sky in March

As we celebrate the official arrival of spring in the Northern Hemisphere, we bid adieu to the stars of winter.

This was the scene last night from my backyard, of Orion and the surrounding constellations of the winter sky setting into the southwest in the early evening. Each night they will set sooner and sooner, even as the nights continue to grow shorter and the Sun sets later.

By late April Orion will be gone from our Northern Hemisphere sky — he hangs around until well into May for sites south of the equator.

Panorama of the Winter Sky in March (with Labels)
A horizon-to-zenith panorama of the winter consellations on a March evening as they set into the southwest. Taken from home March 19, 2017. This is a panorama of 5 panels, each with the 20mm Sigma Art lens at f/2, and Nikon D750 at ISO 3200, for 25 seconds each. Stitched with Adobe Camera Raw.

In this version I’ve labeled the main characters in this winter hunting scene – including some of the deep-sky “Messier”  objects like M45, the Pleiades; M44, the Beehive star cluster; and M42, the Orion Nebula.

At the same time this year, we also say goodbye to Venus which has shone so brightly these last few months as an evening star. By this weekend, it will be lost from sight as it passes between Earth and the Sun.

Mercury Rising and Venus Descending (with Labels)
Mercury (left) and Venus (right and bright) shinng low in the evening twilight, on March 19, 2017. Mercury was then 2 weeks before greatest elongation while Venus was a week before inferior conjunction. So Mercury was rising into the evening sky while Venus was rapidly descending. This is a 7-image HDR stack of exposures from 2.5 seconds to 1.6-second at ISO 200 with the Canon 6D and with the Sigma 50mm lens at f/4.

Meanwhile, Mercury is rising into view in the evening twilight, in its best evening showing of the year from northern latitudes. The view below is also from March 19, with Mercury to the left of brighter Venus.

Over the next two weeks, look low in the west for a bright star amid the twilight. Mercury appears farthest from the Sun on April 1, the date of its “greatest elongation.”

Having Mercury in our evening sky is a sure sign of spring.

Leo and the Spring Stars Rising
Leo rising in the east along with the northern hemisphere spring stars. Numerous satellite trails are visible. I didn’t clone them out. This is a vertical panorama of 4 frames, with the 20mm Sigma Art lens at f/2 and 25 seconds at ISO 3200 with the Nikon D750. Stitched with PTGui using Transverse Equirectangular projection.

Another sign of spring is Leo the lion.

While Orion sets in the west, the stars of spring are rising in the east. The panorama above depicts the scene in the eastern sky these nights, as Leo rises below the Big Dipper.

The Big Dipper is at upper left, with its handle pointing down to Arcturus at bottom left. The Bowl of the Dipper points down to the right to Regulus and the stars of Leo.

Above Leo is the star cluster M44, the Beehive, in Cancer. Below Leo at centre is the star cluster Mel 111, the Coma Berenices star cluster near the North Galactic Pole.

Happy Equinox!

— Alan, March 20, 2017 / © 2017 Alan Dyer / amazingsky.com





Heads Up! – Planets Pair with Clusters


April 11 Venus & M45

Look west and south this weekend to see the two brightest planets each pairing with a bright cluster of stars.

This weekend, Venus and Jupiter each pair with a prominent open star cluster.

In the west, look for brilliant Venus, an evening “star” this spring, shining near the Pleiades, or Seven Sisters star cluster. Some know it as Messier 45.

Both Venus and the Pleiades are in Taurus the bull, whose main stars lie to the left of the Venus-Pleiades pairing. Farther to the left still, look for the distinctive stars of Orion the hunter, whose trio of Belt stars give him away.

April 11 Venus & M45 CU

As this close up shows, binoculars will nicely frame Venus and the Pleiades at once.

Venus continues to climb higher this spring while the Pleiades and the other stars of the winter sky, including Orion and Taurus, sink lower and lower. The next few nights are the best for catching Venus as it passes the Pleiades.

April 11 Jupter & M44

High in the south as it gets dark shines the other bright planet in our sky – Jupiter.

It, too pairs with a star cluster. Jupiter now shines a binocular field to the east (left) of the Beehive Cluster, also known as Messier 44. Jupiter and M44 lie in Cancer the crab, a faint constellation nestled between Leo to the east and Gemini to the west.

Jupiter has been retrograding closer to the Beehive all winter and early spring. But this weekend Jupiter sits as close to the cluster as it is going to get. For the rest of spring and summer Jupiter will move east away from the Beehive.

Look west and south as it gets dark this weekend, for the pair of planet-cluster pairings!

Clear skies and happy stargazing.

– Alan, April 9, 2015 / © 2015 Alan Dyer / www.amazingsky.com



Orion Over and Through Turret Arch


Orion Star Trails Through Turret Arch

What a fabulous night for some nightscapes at Arches National Park, Utah.

I’m at Arches National Park for two nights, to shoot the stars over its amazing eroded sandstone landscape.

I started the night last night, April 6, shooting Orion over Turret Arch while the sky was still lit by deep twilight. That image is below. It shows Orion and the winter sky, with bright Venus at right, setting over the aptly-named Turret Arch.

I scouted the location earlier in the day and measured in person, as expected from maps, that the angles would be perfect for capturing Orion over the Arch.

But better still would be getting Orion setting through the Arch. That’s the lead photo at top.

I shot the star trail image later in the evening, over half an hour. It uses a stack of 5 exposures: a single, short 30-second one for the initial point-like stars, followed by a series of four 8-minute exposures to create the long star trails. The short exposure was at ISO 4000; the long exposures at ISO 250. All are with the Rokinon 14mm lens.

Orion Over Turret Arch

Arches is a popular and iconic place for nightscape photography.

I thought I’d likely not be alone, and sure enough another pair of photographers showed up, though they were armed with lights to illuminate the Arches, as many photographers like to do.

I shot this from afar, as they lit up the inside of Turret Arch where I had been earlier in the night.

Photographer Lighting Turret Arch

I prefer not to artificially illuminate natural landscapes, or do so only mildly, not with bright spotlights. We traded arches! – while I shot Turret, the other photography couple shot next door at the North and South Window Arches, and vice versa. It all worked out fine.

Later in the night, after moonrise, I shot next door at the famous Double Arch. Those moonlit photos will be in tomorrow’s blog.

It was a very productive night, and a remarkable experience shooting at such a location on a warm and quiet night, with only a fellow photographer or two for company.

– Alan, April 7, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Lovejoy Passes the Pleiades


Comet Lovejoy and the Pleiades (Jan 18, 2015)

Tonight Comet Lovejoy paired with the Pleiades star cluster.

Sunday, January 18 was the night to catch the ever-photogenic Comet Lovejoy at its best and closest to the Seven Sisters, the Pleiades. Its long blue ion tail stretched back past the Pleiades.

I thought the tail would be passing right over the star cluster, but not so. At least not when I was shooting it at about 7:30 pm MST.

Still, the combination made a fine pairing of cosmic blue objects for the camera. The top image is with a 135mm telephoto.

Comet Lovejoy in the Winter Sky (Jan 18, 2015)

This wide-angle image, with a 24mm lens, takes in many of the northern winter constellations, from Orion at bottom, to Auriga at top, with Taurus in the middle. Notice the dark tendrils of the Taurus Dark Clouds.

At right, beside the Pleiades, is the green and blue comet, with its tail reaching back past the Pleiades.

I shot both images from the dark skies of City of Rocks State Park, New Mexico, which has proven to be one of the finest places on the planet for watching Lovejoy!

– Alan, January 18, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Comet Lovejoy Moving Amid the Stars


Comet Lovejoy near the Pleiades (Jan 15, 2015)

Comet Lovejoy is now at its best. I captured a time-lapse of it moving through the stars.

Last night I shot Comet Lovejoy with a couple of cameras. One, using a telephoto lens, captured the green comet with its long blue ion tail near the blue Pleiades star cluster (at top). The comet is passing west of the Pleiades over the next few nights, providing some wonderfully photogenic compositions.

Clear skies most of the night allowed me to also shoot through the telescope, taking 280 close-up images of the comet over 5 hours as the telescope tracked the stars. Assembled into a time-lapse movie, the result shows the comet slowly gliding against the background stars in its orbit around the Sun.

Expand the video frame to see it properly.

Each of the 280 frames is a 1-minute exposure, taken at ISO 6400, using a TMB 92mm refractor at f/4.4. I started the sequence just before 7pm and ended it just before midnight. So the movie records about 5 hours of motion.

Toward the end some cloud drifting through causes the stars to bloat up momentarily. And as the comet set lower into the west sky conditions got worse compared to the start of the sequence when the comet was at its highest in the south.

However, judicious processing using the time-lapse software LRTimelapse and Sequence helped compensate for the changing sky conditions.

Do take a look at this fine comet. The tail is visible in binoculars from a dark site.

– Alan, January 16, 2015 / © Alan Dyer 2015 / amazingsky.com

The Seven Sisters in a Silver Braid


M45 Pleiades Star Cluster, the Seven Sisters“Many a night I saw the Pleiads, rising thro’ the mellow shade,

Glitter like a swarm of fireflies tangled in a silver braid.”

– Alfred, Lord Tennyson

These are the famous Seven Sisters, the Pleiades, caught two nights ago in New Mexico skies. This bright star cluster stands out easily to the unaided eye in the winter sky, shining in the shoulder of Taurus.

What the eye does not see is the “silver braid” – the dim dust that surrounds the Pleiades. The stars light the dust, causing it to shine blue near the stars. Farther out, the dust is much dimmer and glows with pale tints of cyan and red.

The dust clouds were once thought to be what was leftover from the formation of the stars, now estimated to have occurred about 100 million years ago. However, current theory suggests that the natal dust of the Pleiads would have long since dispersed.

Instead, the silvery braids of dust that surround the Seven Sisters are just nearby dust clouds in Taurus that the stars are passing through, and illuminating with their hot blue light.

The Pleiades, as familiar as they are – they have been mentioned in ancient texts and myths dating back thousand of years – remain a source of scientific controversy. Astronomers argue over their distance, with different methods providing different results. But the best recent measurement puts them 440 light years away.

Technical notes: This is a stack of 10 x 12 minute exposures at ISO 400 with the Canon 5D MkII camera and 92mm TMB refractor at f/4.4. I shot the images November 16 from near Silver City, New Mexico.

– Alan, November 18, 2014 / © 2014 Alan Dyer



Red Moon over Writing-on-Stone


Red Moon over Writing-on-Stone

The red eclipsed Moon shines over the Milk River, with Orion over the Sweetgrass Hills.

This was the scene at 4:45 this morning, October 8, from my observing site for the lunar eclipse, Writing-on-Stone Provincial Park in southern Alberta.

The eclipsed red Moon shines at far right over the Milk River and sandstone formations of Writing-on-Stone Park, home to ancient petroglyphs, and a sacred site to First Nations people.

At left are the Sweetgrass Hills across the border in Montana. Above shine the stars of Orion, with his Dog Star Sirius below. Above is Taurus, with Aldebaran and the Pleiades cluster.

The night was fairly clear for the hour of totality, though with high haze fuzzing the stars and Moon. But considering the cloud I had driven 3 hours to escape I was happy.

Self-Portrait at Oct 8, 2014 Total Lunar Eclipse

Here I am in a 5:30 a.m. selfie by starlight and moonlight, with the clouds I had escaped now rolling in to cover the Moon as it began to emerge from Earth’s shadow.

No matter. I had captured what I had come for: the nightscape above (with a 14mm lens), and close-ups shot through this telescope gear, one of which I featured in my previous post.

– Alan, October 8, 2014 / © 2014 Alan Dyer



Mount Kobau Nightscapes


Big Dipper Down the Road

The pines and sagebrush landscape of the summit of Mount Kobau are illuminated by the light of just the stars and Milky Way.

This collection of images from Monday night, July 28, captures the night sky above and the land below in classic “nightscapes.”

I took all of these with a camera on a static tripod, with no tracking system involved here. All are about 40-second exposures at ISO 3200 to 6400 with a fast 24mm lens at f/2.5 on a Canon 6D.

However, for the image above I composited two exposures: a shorter 40 second shot for the sky and a longer 1 minute 40 second shot for the ground. I used Photoshop’s Quick Selection tool to make a rough selection of the ground, then the Refine Mask and Smart Radius tool to refine the edge to precisely mask the sky separately from the ground, for individual processing.

The top image shows the Big Dipper and a well-timed meteor, at the end of the summit road on Mt. Kobau, near Osoyoos, BC.

Big Dipper & Arcturus from Mt Kobau

This image takes in the Big Dipper at right pointing down to Arcturus at left. I used Photoshop’s Content Aware Fill to neatly eliminate a power pole and wires.

Sagebrush and Stars

Looking southwest reveals the Milky Way above the sagebrush and pine trees. This is a single exposure, with the ground processed with Shadow detail recovery to bring out the starlit ground.

Pleiades Rising Down the Road

This image, taken about 2 a.m., records the Pleiades star cluster rising down the end of the summit road, with Capella at left. It is a dual-exposure composite: 40 seconds for the sky and 1m40s for the ground.

I gave a talk at this year’s Mt. Kobau Star Party on how to shoot these kinds of nightscapes, illustrated with some of these images shot on site the night before. Very nice!

– Alan, July 30, 2014 / © 2014 Alan Dyer



The Pleiades – The Stellar Seven Sisters


M45, the Pleiades Cluster (92mm 5DII)

The stars of the Pleiades sit amid a dusty sky in Taurus.

These are the famous Seven Sisters of Greek legend, known as the Pleiades. They are the daughters of Atlas and Pleione, who are also represented by stars in the cluster. Many cultures around the world tell stories about these stars, but in Greek tradition their appearance signalled the summer sailing season in the Mediterranean. The Pleiades first appear at sunset in the eastern evening sky in autumn and put in their last appearance in the western sky in spring.

One story has it they were placed in the sky to recognize their devotion to their father Atlas and his unending labour in holding up the heavens. They are the half-sisters of the Hyades, another nearby cluster of stars in Taurus. Other stories describe the Pleiades as the Seven Doves that carried ambrosia to the infant Zeus.

A seldom-used name now for this cluster is the Atlantides, from the plural form of Atlas, their father. Thus, these sisters gave their name to the Atlantic Ocean, a vast and uncharted sea until the 16th century. The term “atlas,” first used by Mercator for a book of maps, comes not from the Pleiades’ father but from a real-life king in Morocco who supposedly made one of the first celestial globes.

I shot this portrait of the Sisters a few nights ago, stacking a set of five 15-minute exposures with the TMB 92mm refractor and Canon 5D MkII at ISO 800. I processed the image to bring out the faint clouds of dust that pervade the area.

The Pleiades are passing through dust clouds in Taurus and lighting them up. The stars are embedded in dust, lit blue by the light of the hot stars. But even farther out you can see wisps of dust faintly illuminated by the light of the Pleiades.

The stars are thought to be about 100 million years old, quite young as stars go. They formed together in a massive nebula that has long since dissipated, and will travel together for another few hundred million years until the sister stars go their own way around the Galaxy. The stellar family that gave rise to so many legends around the world will be scattered to the stars.

– Alan, October 12, 2013 / © 2013 Alan Dyer

Pleiades Rising Through the Old Farm Gate


Pleiades Through the Old Farm Gate

The Pleiades rises beyond the old farm gate on a moonlit prairie night.

It’s been a wonderful few nights for nightscape photography, with a bright gibbous Moon lighting the golden prairie landscape. Skies have been clear and the nights warm, ideal for 3-hour shoots of old farmsteads and prairie scenes.

I’ve spent the last few nights at the abandoned farm near home, shooting time-lapses. This is from Monday night, and is one frame from a 360-frame dolly-motion time-lapse.

The Pleiades star cluster rises in the east over the old barn and farm gate. A car travels through the coulee, leaving a streak of headlights.

I hope the weather continues, so I can harvest some more images, making time-lapse “hay” while the Moon shines!

– Alan, September 17, 2013 / © 2013 Alan Dyer



Goodbye Winter Sky!


Orion & Winter Sky Setting (24mm 5DMkII)

Say goodbye to the winter sky, now sinking fast into the sunset. The departure of Orion and company is an annual sign of spring.

Look west on a clear night in the next couple of weeks and you’ll see this scene, as Orion sinks into the sunset, surrounded by Taurus to the right of him, and Canis Major to the left of him. Taurus is his foe, Canis Major his friend.

Having so many bright stars in the April evening twilight makes for a beautiful scene in the deepening blue. But I suspect most of us are happy to see all signs of winter gone for a long time!

I shot this Monday night, April 1, on a very clear night. Orion’s Belt is just left of centre. The trio of Belt stars points left and down to Sirius, the Dog Star, and points right and up to Aldebaran, the Bull’s Eye. Above Aldebaran is brilliant Jupiter. Just at the right edge of the frame are the Seven Sisters, the Pleiades.

Say goodbye to these stars of winter. We won’t see them again until late summer in the pre-dawn sky.

– Alan, April 2, 2013 / © 2013 Alan Dyer

Winter Stars Rising


The Winter Sky, Northern Hemisphere

Yes, it’s cold out there, but a clear evening away from city lights this week – or this winter – will reward you with the sight of a rising star-filled sky.

This is the winter sky of the northern hemisphere, rising above a snowy prairie landscape, in a shot I took Sunday night, January 6, 2013. The sky is populated by a ream of bright stars and constellations, anchored by Orion, just below centre. You can see his three Belt stars pointing down to Sirius, just peering above the horizon in the glow of a distant town. Orion’s Belt points up to Aldebaran, the V-shaped Hyades star cluster, and bright Jupiter (the brightest object in the scene, above centre), all in Taurus. Above Jupiter is the Pleiades star cluster.

The Milky Way runs down the sky from Auriga to Canis Major. This week, January 6 to 13, is a good week to see the winter Milky Way, as it’s New Moon and the sky is dark.

In this scene the camera was looking southeast about 9 p.m. Sirius has just risen. By midnight the Dog Star shines due south. I used a 15mm wide-angle lens to take in the entire sweep of the winter sky from horizon to zenith. This is a stack of four 4-minute exposures, though the landscape is from just one of the frames, to minimize the blurring caused by the camera tracking the sky. Some clouds moving in add the streaks on either side of the frame. It was a wonderful sky, while it lasted!

And I’m pleased to note that this is my 250th blog post since beginning AmazingSky.net two years ago in early 2011. I hope you have enjoyed the sky tours.

– Alan, January 6, 2013 / © 2013 Alan Dyer

Jupiter Amid the Clusters of Taurus


Jupiter in Taurus (January 4, 2013)

Look up on a clear night this season (winter for us in the northern hemisphere) and you’ll see a bright object shining in Taurus the bull. That’s Jupiter.

This year Jupiter sits in a photogenic region of the sky, directly above the stars of the Hyades star cluster and yellow Aldebaran, the brightest star in Taurus. Above and to the west (right) of Jupiter is the blue Pleiades star cluster.

Over the course of January 2013 you’ll be able to see Jupiter move a little further west each night (to the right in this photo) away from Aldebaran and toward the Pleiades. Jupiter will stop its retrograde motion on January 30. After that it treks eastward to again pass above the Hyades and Aldebaran (returning to where it is now) in early March.

Jupiter’s proximity to Aldebaran and the Hyades makes it easy to follow its retrograde loop over the next few weeks. It’s an easy phenomenon to watch, but explaining it took society hundreds of years and the ultimate in paradigm shifts in thinking, from the self-important arrogance that Earth – and we – were the centre of the universe, to the Sun-centered view of space, with Earth demoted to being just one planet orbiting our star.

I took this image Friday night, January 4, from home as my first astrophoto upon returning to Canada from Australia. It’s a combination of two sets of images: one taken “straight & unfiltered” and one taken through a soft-focus filter to add the glows around the stars and central, brilliant Jupiter. I then blended the filtered images onto the normal images in Photoshop with the Lighten blend mode.

– Alan, January 5, 2013 / © 2013 Alan Dyer

Australian Sky Panorama


Timor Cottage Panorama #1

This is the southern hemisphere sky in a 360° panorama.

From left to right in the sky, you can see:

– in the South: the two Magellanic Clouds, satellite galaxies of the Milky Way

– in the West: the diagonal glow of Zodiacal Light

– in the North: Orion, Jupiter and the Pleiades above the outline of Timor Rock

– in the East: the southern Milky Way just rising

I shot this last night in the early evening, Sunday, December 9, from my observing site in Australia, Timor Cottage at Coonabarabran, NSW. It’s a panorama of 8 images, each a 1 minute untracked exposure with the 10-22mm lens at 10mm. I’m amazed at how well the sections join together, considering the stars are moving from one frame to the next and about 16 minutes separates the beginning and end frames.

– Alan, December 10, 2012 / © 2012 Alan Dyer



Jupiter Rising


Look east now late at night and you’ll see Jupiter rising amid the stars of Taurus.

I took this shot a week ago from my rural backyard on the last clear night I’ve had. Remarkably, I had  bought a new camera – a Canon 60Da – earlier that day and was actually able to try it out. This is the first real shot I took with it. It shows Jupiter amid the horns of Taurus the bull, and below the Pleiades. A faint aurora lights up the northern sky at left.

There have been some superb aurora displays in the last week but clouds just got in the way.

This is my 200th blog post since I began AmazingSky.net in early 2011. I hope you have enjoyed the images and will continue to do so. Thanks for looking!

– Alan, October 15, 2012 / © 2012 Alan Dyer

Perseid Meteors and Planets over a Mountain Lake


It was quite a night, and a wonderful dawn. This was the scene at the end of a night of falling stars.

A trio of Perseid meteors zips down at left, while at right a trio of solar system worlds rises into the pre-dawn sky. The overexposed waning Moon is flanked by Jupiter above and Venus below. Jupiter shines near the Hyades star cluster and below the Pleiades cluster.

I took this shot (it is actually a composite of three shots, each with its own meteor) on the morning of Sunday, August 12 on the peak night of the annual Perseid meteor shower, widely publicized this year due to the lack of a Moon for most of the night, and the convenience of falling on a weekend. The scene is looking east over Lake Minnewanka in Banff National Park, Alberta, one of the few places in this part of the Rockies you can look east to a reasonably unobstructed sky.

Notice the glitter path on the water from not only the Moon but also Venus.

— Alan, August 13, 2012 / © 2012 Alan Dyer

Venus Meets the Seven Sisters


The goddess of love meets the daughters of Atlas — it isn’t often we get to see such a sight!

This is brilliant Venus shining amid the stars of the Pleiades, on the evening of Tuesday, April 3, 2012, with Venus as close to the Seven Sisters star cluster as I can ever remember seeing.

Venus last passed near the Pleiades in April 2004 (though not as closely as it did tonight), and will again in April 2020, reflecting the 8-year periodicity of Venus’s return to the same place in the sky. Thus the 8-year interval between the June 2004 transit of Venus and the one this June in 2012.

I took this through a 92mm aperture refractor, but added the classic spikes of light (which you would normally get only when shooting through a Newtonian reflector telescope) by taping some wire in front of the lens. It’s a technique that’s strictly for show. Some high cloud moving in, supposedly in advance of a big spring snowstorm, added the glow around Venus.

This was one of many superlative Venus events this year. Enjoy the sight of Venus now that it is as high as it ever gets in our northern hemisphere evening sky. We won’t see it quite as good as this again until 2020.

— Alan, April 3, 2012 / © 2012 Alan Dyer

Celestial Pinks and Blues




Who says the dark night sky isn’t colourful? Of course, to the naked eye it mostly is, with the darkness punctuated only with a few red, yellow and blues stars. But expose a camera for long enough and all kinds of colour begins to appear.

This region is above us now, in the Northern Hemisphere evening sky for mid-winter. It’s the boundary area between Taurus and Perseus. Below are the vivid blues of the hot young Pleiades star cluster in Taurus. At top, just squeezing into the frame, is the shocking pink of the California Nebula, a glowing cloud of hydrogen gas in Perseus.

But between are the subtle hues of faint nebulosity weaving all through the Perseus-Taurus border zone. Below are faint cyans and blues from dust clouds reflecting the light of the Pleiades stars. In the middle are the yellow-browns of dark dust clouds hardly emitting light at all, but snaking across the frame to end in a complex of pink and blue straddling the border collectively known as IC 348 and IC 1333. At top, the glowing hydrogen gas of the California emits a mix of red and blue wavelengths, creating the hot pink tones, but fading to a deeper red to the left as the nebula thins out to the east. Throughout, hot blue stars pepper the sky and help illuminate the dust and gas clouds which will likely form more hot stars in the eons to come.

I took this shot last Wednesday night, on one of the few clear, haze-free nights of late. This is a “piggybacked shot,” with the Canon 5D MkII camera going along for the ride on one of my tracking mounts. This final shot is a stack of five 6-minute exposures, highly processed to bring out the faint clouds barely brighter than the sky itself. The camera was equipped with a 135mm telephoto lens, giving a field of view a couple of binocular fields wide. Hold out your hand and your outstretched palm would nicely cover  this area of sky. But only the camera reveals what is actually there.

— Alan, January 29, 2012 / Image © 2012 Alan Dyer

Dawn Sky Serenity


Some sky scenes are worth getting up early for. This was the dawn sky this morning, July 25, at about 4:20 a.m., looking east to the rising crescent Moon, which this morning appeared near the Pleiades star cluster. You can see it just above the overexposed Moon.

The waning Moon also sits between two planets now in the pre-dawn sky: Jupiter, the bright object at upper right, and Mars, about the same distance away from the Moon but to the lower left. Mars, the Moon and Jupiter form a diagonal line across the dawn sky that defines the dawn ecliptic. Also in the scene is the V-shaped Hyades star cluster, and the bright star Aldebaran, just below the Moon.

This was a 5-second exposure with the Canon 24mm lens at f/3.5 and Canon 5D MkII camera at ISO 800.

— Alan, July 25, 2011 / Image © 2011 Alan Dyer



Pursuing Perseus


One of the tenets of my astrophotography “philosophy,” if there can be such a thing (my university degree is in Philosophy after all), is to not spend an enormous amount of time and money chasing after the same images others do, knowing they will likely get far better results than I might achieve, given my location and choice number of clear skies. I don’t live in Arizona, New Mexico or Chile.

Yes, there are certain showpiece objects one is obliged to shoot, to add to the portfolio. But rather than go after many of the usual galaxies and nebulas, I often prefer to shoot wider-field targets that others often bypass.

Simple shots of constellations are often more in demand by publishers than closeups of deep-sky objects, and yet are usually in short supply, as many astrophotographers dismiss them as being “just for beginners.” But good constellation shots still take the right gear, techniques and skies to stand out. Only now am I getting the results I’ve long sought.

With new techniques now in hand, one of my goals is to accumulate a complete portfolio of constellation portraits, though not all of these star patterns stand out as being photogenic. But this one does.

This shot is a recent favourite of mine, of the constellation of Perseus, a rich area of sky. Modern digital cameras show it as the old film cameras never could, laced with reddish dark nebulas of different densities. The Milky Way through this region takes on such a variety of subtle hues achieving correct colour balance is tough.

At top is the loose collection of hot blue stars known as the Perseus Association. At bottom is the most famous tightly bound cluster of stars, the Pleiades. Between is the finger of glowing hydrogen gas called the California Nebula. This photo is an example of how “simple constellation” shots can take on a beauty of their own.

– Alan, February 2011 / Image © 2011 Alan Dyer

The Wonderful Winter Sky


While I took this image a year ago in early 2010, I thought I’d post this up now, with the new blog now underway. This is a mosaic of what surely ranks as one of the most amazing areas of sky — the vast panorama of the night sky visible in the northern hemisphere each winter. Here we see more bright stars than at any other season of the year, in the constellations (in clockwise order) of Orion, Canis Minor, Gemini, Auriga, and Taurus. Canis Major and its luminary, Sirius, are just off the bottom of the frame.

This is a 4-panel mosaic, each panel consisting of four 4-minute exposures plus two 4-minute exposures with a soft diffuser filter to add the star glows. Each was taken at ISO 800 with the Canon 5D MkII and a 35mm lens at f/4. Slight haze, changing sky fog, and changing elevation of the fields make it tough to get consistent colours across the sky during the couple of hours of exposure time needed to grab the images for such a mosaic, especially from my home latitude. But this attempt worked pretty well and records the wealth of bright red and dark nebulosity throughout this area of sky, a region of the Milky Way in our spiral arm but a little farther out from the centre of the Galaxy than where we live.

– Alan, January 2011 / Image © 2010 Alan Dyer

The Dark Clouds of Taurus


An area of sky often neglected but ideal for digital imaging is the region of Milky Way in Taurus and Auriga. Threaded through this area of sky are large lanes of dark interstellar dust, forming cold molecular clouds out of which stars form. This complex is close, only 400 light years away, in our spiral arm of the Galaxy, and so is spread out over a wide area of sky. Only piggybacked cameras with normal and wide-angle lenses capture it. But today’s digital cameras are able to record these kinds of dark nebulae as more than just dark holes in the sky — they have colour, usually shades of reddish-brown.

This is a shot from January 2011 from my home backyard, and takes in all of Taurus, most of Auriga and southern Perseus, with the Pleiades at right and the Hyades below.

— Alan, January 2011 / Image © 2011 Alan Dyer
