The Cadence of the Moving Sky


Saturn, Mars and the Milky Way over the Bow River

Saturn, Mars and the Milky Way appeared in the twilight over the Bow River.

I shot this scene on August 24 from the viewpoint at Blackfoot Crossing Historical Park, overlooking the Bow River. Mars appears between Saturn above and Antares below, in a line of objects west of the Milky Way.

The valley below is the traditional meeting place of the Blackfoot Nation, and the site of the signing of Treaty Seven between Chief Crowfoot and Colonel MacLeod of the North West Mounted Police in 1877.

The image is a panorama of two images, each 20-second exposures at f/2 and ISO 1600 with the 24mm lens. I shot them just prior to shooting time-lapses of the moving sky, using two cameras to create a comparison pair of videos, to illustrate the choices in setting the cadence when shooting time-lapses.

The movies, embedded here, will be in the next edition of my Nightscapes and Time-Lapse ebook, with the current version linked to below. The text explains what the videos are showing.



Choose Your Style

When shooting frames destined for a time-lapse movie we have a choice:

  • Shoot fewer but longer exposures at slower ISOs and/or smaller apertures.

OR …

  • Shoot lots of short exposures at high ISOs and/or wide apertures.



The former yields greater depth of field; the latter produces more noise. But with time-lapses, the variations also affect the mood of a movie in playback.

This comparison shows a pair of movies, both rendered at 30 frames per second:

Clip #1 was taken over 2 hours using 20-second exposures, all at ISO 2000 and f/2 with 1-second intervals. The result was 300 frames.

Clip #2 was taken over 1 hour using 5-second exposures also at f/2 and 1-second intervals, but at ISO 8000. The result was 600 frames: twice as many frames in half the time.

Clip #1 shows fast sky motion. Clip #2 shows slow motion.

Clip #2 exhibits enough noise that I couldn’t bring out the dark foreground as well as in Clip #1. Clip 2 exhibits a slower, more graceful motion. And it better “time-resolves” fast-moving content such as cars and aircraft.

Which is better? It depends …

Long = Fast

The movie taken at a longer, slower cadence (using longer exposures) and requiring 2 hours to capture 300 frames resulted in fast, dramatic sky motion when played back. Two hours of sky motion are being compressed into 10 seconds of playback at 30 frames per second. You might like that if you want a dramatic, high-energy feel.

Short = Slow

By comparison, the movie that packed 600 frames into just an hour of shooting (by using short exposures taken at fast apertures or fast ISOs) produced a movie where the sky moves very slowly during its 10 seconds of playback, also at 30 frames per second. You might like that if you want a slow, peaceful mood to your movies.

So, if you want your movie to have a slow, quiet feel, shoot lots of short exposures. But, if you want your movie to have a fast, high-energy feel, shoot long exposures.

As an aside – all purchasers of the current edition of my ebook will get the updated version free of charge via the iBooks Store once it is published later this year.

— Alan, August 26, 2016 / © 2016 Alan Dyer / AmazingSky.com



Mars in the Moonlight


Mars in the Badlands

Mars is approaching! It now shines brightly in the midnight sky as a red star in Scorpius.

You can’t miss Mars now. It is shining brighter than it has since 2005, and is about to come as close to Earth as it has in 11 years as well.

Mars is now approaching opposition, when the Earth comes closest to Mars, and the Sun, Earth and Mars lie along the same line. Opposition date is May 22. That’s when Mars shines at its brightest, at magnitude -2.1, about as bright as Jupiter. Only Venus can be a brighter planet and it’s not in our sky right now.

A week later, on May 30, Mars comes closest to Earth, at a distance of 75 million kilometres. That’s when the disk of Mars looks largest in a telescope. And you will need a telescope at high power (150x to 250x) to make out the dark markings, north polar cap, and bright white clouds on Mars.

Mars in the Moonlight (May 13, 2016)
Mars above Antares, with Saturn to the left, low in the south on May 13, 2016, in the moonlight of a waxing quarter Moon, from home in Alberta. This was one week before opposition and two weeks before closest approach, so Mars is particularly bright and red. However, from my latitude of 50° N Mars appears low in the south. This is a single 15-second exposure, untracked, at f/2.5 with the 35mm lens and Canon 6D at ISO 2000.

In these views, I show Mars shining as a bright reddish star low in my western Canadian sky. I shot the lead image from Dinosaur Provincial Park on May 16. The image just above was from my backyard the night before.

This week, Mars is passing between Beta and Delta Scorpii, two bright stars in the head of Scorpius, as the red planet retrogrades westward against the background stars.

Saturn shines to the east (left) of Mars now, with both planets shining above the red giant star Antares in Scorpius. In these photos they form a neat triangle.

Even without a telescope to magnify the view, it’ll be rewarding to watch Mars with the unaided eye or binoculars as it treks west out of Scorpius into Libra this spring and summer. It stops retrograding on June 30, then starts looping back into Scorpius, for a rendezvous with Antares and Saturn in late August.

This little compilation of time-lapse movies shows Mars, Saturn, and the rest of the sky, rising into the southeast and across the south on two nights this past week.

Be sure to explore Mars this month and next, whether by eye or by telescope. It’s the best we’ve seen it in a decade.

It’s next close approach in 2018 will be even better, though Mars will appear even lower in our northern sky.

– Alan, May 17 / © 2016 Alan Dyer / amazingsky.com



Toward the Centre of the Galaxy


Toward the Centre of the Galaxy

From southern latitudes the most amazing region of the sky shines overhead late on austral autumn nights.

There is no more spectacular part of the Milky Way than the regions around its galactic centre. Or at least in the direction of the galaxy’s core.

We can’t see the actual centre of the Galaxy, at least not with the cameras and telescopes at the disposal of amateur photographers such as myself.

It takes large observatory telescopes equipped with infrared cameras to see the stars orbiting the actual centre of the Milky Way. Doing so over many years reveals stars whipping around an invisible object with an estimated 4 million solar masses packed into the volume no larger than the solar system. It’s a black hole.

By comparison, looking in that direction with our eyes and everyday cameras, we see a mass of stars in glowing clouds intersected by lanes of dark interstellar dust.

The top image shows a wide view of the Milky Way toward the galactic centre, taking in most of Sagittarius and Scorpius and their incredible array of nebulas, star clusters and rivers of dark dust, all located in the dense spiral arms between us and the galactic core.

Starclouds and Stardust – Mosaic of the Galactic Centre
This is a mosaic of 6 segments, each segment being a stack of 4 x 3-minute exposures at f/2.8 with the 135mm Canon L-Series

Zooming into that scene reveals a panoramic close-up of the Milky Way around the galactic centre, from the Eagle Nebula in Serpens, at left, to the Cat’s Paw Nebula in Scorpius, at right.

This is the richest hunting ground for stargazers looking for deep-sky wonders. It’s all here, with field after field of telescopic and binocular sights in an area of sky just a few binocular fields wide.

The actual galactic core area is just right of the centre of the frame, above the bright Sagittarius StarCloud.

Centre of the Galaxy Area
This is a stack of 5 x 5 minute exposures with the Borg 77mm f/4 astrograph and filter-modified Canon 5D MkII at ISO 1600, taken from Tibuc Cottage near Coonabarabran, NSW, Australia.

Zooming in again shows just that region of sky in an even closer view. The contrast between the bright star fields at left and the dark intervening dust at right is striking even in binoculars – perhaps especially in binoculars.

The visual impression is of looking into dark canyons of space plunging off bright plateaus of stars.

In fact, it is just the opposite. The dark areas are created by dust much closer to us, hiding more distant stars. It is where the stars are most abundant, in the dust-free starclouds, that we see farthest into the galaxy.

In the image above the galactic centre is at right, just above the small diffuse red nebula. In that direction, some 28,000 light years away, lurks the Milky Way’s monster black hole.

Milky Way Overhead Through Trees
This is a stack of 5 x 6-minute tracked exposures with the 15mm fish-eye lens at f/4 and Canon 5D MKII at ISO 1600. The trees appear to be swirling around the South Celestial Pole at lower right above the Cottage.

To conclude my tour of the galactic centre, I back out all the way to see the entire sky and the Milky Way stretching from horizon to horizon, with the galactic centre nearly overhead in this view from 3 a.m. earlier this week.

Only from a latitude of about 30° South can you get this impressive view, what I consider one of the top “bucket-list” sights the sky has to offer.

– Alan, April 17, 2016 / © 2016 Alan Dyer / www.amazingsky.com



Red Rivals in Scorpius


Red Rivals in Scorpius

Mars outshines his rival red star Antares in the heart of the Scorpion.

This was the view last night from my observing site in Australia, of red Mars shining near the red star Antares, whose very name means “rival of Mars.” But as Mars nears its closest approach to Earth next month it is already far brighter than Antares, easily winning the rivalry now.

The view takes in the head of Scorpius, one of the most colourful areas of the night sky when photographed in long exposures. Uniquely, Antares illuminates a nearby dust cloud with its light which is more yellow than red.

Other dust clouds reflect the blue light of hot young stars in this section of the Milky Way. Red nebulas are emitting their own light from glowing hydrogen.

The area around Antares is also streaked with lanes of dark dust that absorb light and at best appear a dull brown.

Mars reaches its closest point to Earth since 2005 on May 30. All through May and June Mars will shine as a brilliant red star near Antares. A telescope will provide the best view of the red planet we’ve had in a decade.

Saturn and Mars in Scorpius
This is a stack of 4 x 3 minute exposures with the 135mm telephoto lens at f/2.8 and filter-modified Canon 5D MkII at ISO 1600, shot April 14, 2016 from Tibuc Cottage, Australia.

While you are in the area aim your telescope a little to the east to catch Saturn, also in the area, though technically over the border in the constellation of Ophiuchus the Serpent Bearer.

In the view above, Saturn is the bright “star” to the left of Mars. Saturn reaches its closest to Earth in early June. Its rings are now wide open and a spectacular picture postcard sight in any telescope.

Scorpius Rising in Moonlight
This is a stack of 2 x 30-second exposures for the sky and ground, both tracked, plus a 30-second exposure through the Kenko Softon A filter to add the star glows to make the constellation pattern stand out. All with the 35mm lens at f/2 and Canon 6D at ISO 1600. Taken from Tibuc Cottage, Australia.

This final view shows Mars and Saturn rising with Scorpius in the moonlight from two nights ago. From my current latitude of 32° south, Scorpius comes up on his side.

— Alan, April 15, 2016 / © 2016 Alan Dyer  / www.amazingsky.com

Planets in the January Dawn


Waning Moon with Venus & Saturn in Twilight (Jan 6, 2016)

The waning Moon joined Venus and Saturn on a cold winter dawn.

This was the scene this morning, January 6, as the waning crescent Moon met with Venus (bright, at centre) and Saturn (below and left of Venus) in the cold morning twilight.

The grouping appeared above the stars of Scorpius. Antares is just above the treetops.

The top image is with the Canon 60Da and 50mm lens.

The view below, with the 135mm telephoto and Canon 6D camera, is from a half hour earlier before the sky began to brighten with morning twilight.

Waning Moon with Venus & Saturn (Jan 6, 2016)
The waning crescent Moon above Venus and Saturn (dimmer and below Venus) in the pre-dawn sky on January 6, 2016, taken from home on a cold winter morning at -20° C. This is a composite of a long exposure (8s) for the ground, a slightly shorter exposure (6s) for the sky, and shorter exposures for the Moon to avoid it being totally overexposed and to preserve the Earthshine. All with the 135mm lens and Canon 6D.

Venus passes very close to Saturn this weekend, with the two worlds appearing within a telescope field on the mornings of January 8 and 9. Get up early before sunrise and look southeast. Binoculars will provide a superb view.

Venus is hard to miss, but is now dropping lower each morning and will soon be gone from view as it ends its wonderful appearance as a morning star.

— Alan, January 6, 2016 / © 2016 Alan Dyer / www.amazingsky.com



Evening Planet Parade in May


May 21 Venus & Moon

Three planets now shine in the evening sky, including Saturn now at its best for 2015.

Look west in the early evening to sight brilliant Venus in the twilight, and slightly dimmer Jupiter above it. On the evening of Thursday, May 21, look for the waxing crescent Moon below Venus in a wide pairing of the night sky’s two brightest objects.

The Moon appears between Venus and Jupiter on Friday, May 22, and near Jupiter two nights later on Saturday, May 23.

Meanwhile over on the other side of the sky, Saturn is rising at sunset.

May 20 Saturn

As the illustration shows, look southeast after sunset to see Saturn rising along with the stars of Scorpius. Saturn now outshines all the stars of Scorpius, including the red giant star Antares, shining below Saturn.

Saturn is at opposition this weekend, meaning Sun, Earth and Saturn are now lined up with Earth directly between the Sun and Saturn. That puts Saturn as close to us as it gets for 2015, and as bright as it gets.

Being opposite the Sun, Saturn is now rising in the southeast as the Sun sets in the northwest.

A nightscape of antique farm combines illuminated by starlight, with the Milky Way behind. The galactic centre area of Sagittarius and Scorpius lie to the south, with Saturn the brightest object at right. I shot this at the Visitor Centre at the Old Man on His Back Conservation Area in southwest Saskatchewan. The sky is a single 30-second exposure at f/2.8 with the 24mm lens and Canon 5D MkII at ISO 6400. The ground comes from a stack of 8 exposures to smooth noise, all part of a time-lapse/star trail sequence.
A nightscape of antique farm combines illuminated by starlight, with the Milky Way behind. The galactic centre area of Sagittarius and Scorpius lie to the south, with Saturn the brightest object at right. I shot this at the Visitor Centre at the Old Man on His Back Conservation Area in southwest Saskatchewan. The sky is a single 30-second exposure at f/2.8 with the 24mm lens and Canon 5D MkII at ISO 6400. The ground comes from a stack of 8 exposures to smooth noise, all part of a time-lapse/star trail sequence.

Here’s a shot of Saturn, Scorpius, and the Milky Way from early this morning, May 20, taken about 2:30 a.m. when Saturn and Scorpius lay due south. From the latitude of southern Saskatchewan where I am this week, Saturn and Scorpius graze the southern horizon, even in the middle of the night.

– Alan, May 20, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Moon and Twilight Planets over the Bow River


Moon with Antares, Mars & Saturn over Bow River

The waxing Moon shines between Saturn and Mars over the waters of the Bow River.

It was a beautiful autumn evening for watching the twilight showing of the crescent Moon accompanied by Saturn (at right of centre) and the pairing of Mars (at left, above) with his rival red star, Antares in Scorpius (at left, below).

The river is the Bow, with its headwaters at Bow Glacier in Banff.

To shoot this scene I drove to the grounds of the Blackfoot Crossing Historical Park south of Cluny, Alberta to take advantage of its viewpoint overlooking the Bow River and the heart of the traditional Siksika First Nations tribal lands.

It was here, in the valley below, that Treaty Seven was signed between Chief Crowfoot and Colonel James Macleod in September 1877. Today, a beautiful interpretive centre sits on the hillside at the heart of Blackfoot country.

– Alan, September 28, 2014 / © 2014 Alan Dyer



Marvelling at the Milky Way


RAO Milky Way Night Panorama

People gather at a rural observatory to gaze at the Milky Way on a summer night.

The clouds drifted through now and then but skies were mostly clear for the last of the Rothney Astrophysical Observatory‘s annual Milky Way Nights for 2014.

A tradition since 2009 and the Year of Astronomy, these dark-of-the-moon nights at the Observatory have proven hugely popular each summer despite the 10 p.m. start and 2 a.m. finish!

The main image at top shows a 360° panorama as people were gathering at the portable telescopes and lining up – in a blur – for a look inside the observatory domes.

RAO Milky Way Night #1 (Aug 30, 2014)

Roland from the Royal Astronomical Society of Canada provided laser-guided star tours. How did we point out the stars and constellations before green lasers? In the hands of responsible astronomers they are a great tool for public education.

RAO Milky Way Night #4 (Aug 30, 2014)

Here he’s pointing out Vega and the stars of the Summer Triangle. Look way up!

About 400 people attended on Saturday night, the last in a trio of nights this past week. As you can see, the event attracts people of all ages. It’s even a popular date night attraction.

RAO Milky Way Night #6 (Aig 30, 2014)

At these summer stargazing sessions many people bring blankets to just lie back and look up, at a site away from the ugly glow of the city, here lighting up the clouds to the north.

It was a great night of public stargazing!

– Alan, August 31, 2014 / © 2014 Alan Dyer





Standing Under the Stars at Grasslands Park


Standing Under the Stars at Grasslands Park

Grasslands National Park is one of the finest places in Canada to revel in the dark night sky.

This was the scene last night, in far south Saskatchewan, under clear and super dark night skies, at long last after a week of rain, wind and wintery cold.

I’m at Grasslands National Park south of Val Marie, Saskatchewan, to shoot night sky panoramas in what must rank as Canada’s darkest Dark Sky Preserve.

The park itself is new, created only a decade and half ago. It preserves original prairie grasses and is home to unique and rare species. Bison roam here, allowing you to travel back to pre-European times as you gaze out onto a landscape much as it was for thousands of years.

But look up at night and you can gaze at a sky as it was seen for thousands of years, mostly unblemished by the artificial glows of light pollution. Grasslands National Park is a “dark sky preserve,” allowing visitors to see the stars and Milky Way as they should be seen.

I shot this 360° panorama from the Eagle Butte Loop Trail just inside the boundary of the Park. The main hill is 70 Mile Butte, a landmark to the early NorthWest Mounted Police as it lay 70 miles from their posts at Wood Mountain to the east and Eastend to the west.

This view looks out across the farmland to the west and a handful of yard lights. But little else spoils the view around the rest of the horizon. The last vestiges of evening twilight provide a backdrop for the lone silhouette.

The Milky Way arches overhead, and some bands of green airglow, a natural night sky phenomenon, stretch from east to west. The centre of the Milky Way Galaxy lies to the far right, with its glowing clouds of stars.

– Alan, August 26, 2014 / © 2014 Alan Dyer

Sagittarius and Sagebrush


Sagittarius over Sagebrush

Sagittarius and Scorpius shine above the pines and sagebrush of the summit of Mount Kobau, BC.

I’m still working through images I took last week at the Mt. Kobau Star Party. This one looks south toward Washington state amid some smoky air, toward the centre of the Galaxy.

Note the dark lanes in the Milky Way, particularly the prancing “Dark Horse.”

I shot this image the first night I was on the mountain, using a new Sky-Watcher Star Adventurer tracking system.

The image is a stack of five 5-minute tracked exposures with a 24mm lens. The ground is from just one of the exposures to minimize blurring of the ground from the moving camera.

It nicely captures both the sagebrush and the stars of the Milky Way, a quintessential Kobau sky scene.

– Alan, August 5, 2014 / © 2014 Alan Dyer



The Head of the Celestial Scorpion




Scorpius Head & Antares (135mm 5DII) v2The head of Scorpius is laced with colourful nebulas, both bright and dark.

This is an image from two nights ago, from the dark skies of southeast Arizona. It takes in the head of Scorpius, from yellow Antares at lower left as the heart of the Scorpion, to the blue stars at right that mark his head.

The remarkable feature of this region of sky is its colour. No where else in the sky do we see (or I should say, does the camera see) such a spectrum of colourful nebulas. Dark brown lanes run down from the constellation Ophiuchus at left. They meet up with a yellow patch of nebulosity caused by dust reflecting the yellow-orange light of the giant star Antares.

Hot blue stars light up other dusty patches, while the magenta nebulas are created by gas emitting light, not just reflecting light from nearby stars.

A close-up of the region, shot in Australia last month, appears in my blog post from April 17, Stars Scenes in Scorpius. The image above, shot with a 135mm telephoto lens, takes in an area of sky that typical binoculars would frame.

But the eye sees only a hint of the detail, and none of the colour, hidden in the heart of Scorpius.

– Alan, May 6, 2014 / © 2014 Alan Dyer



Nebulas, Clusters and Starfields, Oh My!


Centre of the Galaxy Mosaic

There’s no more spectacular region of the sky than the Milky Way toward the centre of the Galaxy.

What a perfect night it was last night. After moonset between 2 and 3:30 a.m. I shot a series of images around the centre of the Galaxy area and stitched them into a big mosaic of the Milky Way.

The scene takes in the Milky Way from the Eagle and Swan nebulas at top left, down to the Messier 6 and 7 open clusters in Scorpius at bottom. Standing out is the large pink Lagoon Nebula left of centre and the huge region of dark dusty nebulosity popularly called the Dark Horse at right of centre. It’s made of smaller dark nebulas such as the Pipe Nebula and tiny Snake Nebula.

At upper left is the bright Small Sagittarius Starcloud, aka Messier 24, flanked by the open clusters M23 and M25. There are a dozen or more Messier objects in this region of sky.

The actual centre of the Milky Way is obscured by dark dust but lies in the direction just below the centre of the frame, amid one of the bright star clouds that mark this amazing region of sky.

I shot the images for this mosaic from a site near Portal, Arizona, using a 135mm telephoto lens and filter-modified Canon 5D Mark II riding on an iOptron SkyTracker to follow the stars. The mosaic is made of 6 panels, each a stack of five 3-minute exposures. They were all stacked and stitched in Photoshop CC. The full version is 8000 by 9000 pixels and is packed with detail.

I think the result is one of the best astrophotos I’ve taken! It sure helps to have Arizona skies!

– Alan, May 5, 2014 / © 2014 Alan Dyer





Star Scenes in Scorpius


Scorpius Overhead (50mm 5DII)

Scorpius, one of the most photogenic of constellations, contains a wealth of amazing sky sights.

My trip to the land down under is coming to an end but I’m still working through the dozens of deep-sky images I was able to take under the southern stars. The wide-field scene above takes in all of Scorpius, shot with the constellation sitting directly overhead in the pre-dawn hours of an austral autumn. You can trace the scorpion’s winding shape down from his head and claws at top, to his curving stinger tail at bottom.

M6 and M7 Star Clusters in Scorpius (77mm 5DII)

Off the stinger of the scorpion shine two naked-eye star clusters, Messier 6 and 7 (the close-up photo above). M6 is the Butterfly Cluster, seen here sitting in a dark region of the Milky Way at upper right. Its companion, M7, a.k.a. Ptolemy’s Cluster at left of the frame, is lost amid the bright star fields  that mark the direction of the galactic core.

NGC 6334 Cat's Paw Nebula (77mm 5DII)

In the curving tail of the scorpion lie two patches of nebulosity. At upper left is NGC 6357, but the triple-lobed NGC 6334 at bottom right is also known as the Cat’s Paw Nebula.

False Comet NGC 6231 Area (77mm 5DII)

Further up the tail of the scorpion sits this fabulous region of space that is a stunning sight in binoculars. NGC 6231 is the blue star cluster at bottom, which garnered the name The False Comet Cluster back in early 1986 when many people mistook its fuzzy naked eye glow for Comet Halley then passing through the area. The camera reveals the region filled with glowing hydrogen gas.

Antares & Rho Ophiuchi Area (77mm 5DII)

But the standout region of Scorpius lies at its heart. Here, the yellow-orange star Antares lights up a dusty nebula surrounding it, reflecting its yellow glow. At top, another dusty nebula surrounds the star Rho Ophiuchi, reflecting its blue light. Glowing hydrogen gas adds its characteristic magenta tints. This is one of the most colourful regions of the Milky Way.

I shot these images with 50mm normal and 300mm telephoto lenses two weeks ago during the OzSky Star Safari near Coonabarabran, NSW, Australia. For all I used a filter-modified (by Hutech) Canon 5D Mark II camera.

— Alan, April 17, 2014 / © 2014 Alan Dyer



The Galactic Archway of the Southern Sky


Two Styx Night Sky Panorama (Rectilinear)

The southern Milky Way arches across the sky, with the centre of the Galaxy overhead at dawn.

This was the sky at 4:30 this morning, as Venus rose in the east (to the right) amid the zodiacal light, and with the Milky Way soaring overhead. This image is a 360° panorama of the scene, with the zenith, the overhead point, at the top centre of the frame.

The location is the Two Styx Cabins, on the border of New England National Park in New South Wales, Australia. The cabin with the light on (I left it on on purpose for the photo) is where I stayed for two nights in splendid isolation.

The panorama is a stitch of 6 frames shot with an 8mm fish-eye lens, each 1-minute exposures on an untracked tripod. I used the PTGui software program to assemble the pan.

Below is an alternative rendering, in spherical format, to create the more classic “fish-eye” view, but one extending well below the horizon. So this is not one image but a stitch of six.

Two Styx Night Sky Panorama (Fish-Eye)

In this version you can more readily see the spectacle of the Milky Way at dawn in the southern hemisphere autumn months, with the bulge of the galactic core directly overhead as seen from this latitude of 30° south. It is a wonderful sight.

This is my last view of it for this trip. Till next year!

— Alan, April 11, 2014 / © 2014 Alan Dyer



Zooming into the Centre of the Galaxy


Sagittarius and Scorpius Milky Way (35mm 5DII)

A series of closer images zooms us into the Milky Way looking toward the centre of our Galaxy

Here are some images I took this past week at the OzSky Star Safari near Coonabarabran, Australia. The lead image above is a wide-angle lens image of all of Scorpius (above and to the right) and Sagittarius (below and to the left) straddling the Milky Way and its bright glowing core. The direction of the galactic centre is just left of centre of the image. We can’t see the actual centre of the Milky Way with our eyes and normal cameras because there are just too many stars and obscuring dust lanes in between us and the core.

The dust forms marvellous patterns across the glowing Milky Way — see the Dark Horse prancing at left? Long tendrils of dust reach from the feet of the Horse to the bright yellow star at top, Antares, the heart of Scorpius.

The Centre of the Milky Way (50mm 60Da)

This image with a longer lens zooms in closer to the bright Sagittarius Starcloud around the heart of the Galaxy. All along it you can see red and pink nebulas, from the Cat’s Paw at upper right to the Eagle Nebula at lower left. The larger pink object at centre is the Lagoon Nebula.

The next image zooms into the area at the centre of the above shot, just right of the Lagoon.

Sagittarius Starcloud (77mm 5DII)

This is the star-packed Sagittarius Starcloud. Everything you see is stars. Millions of stars.

I took this shot with a 300mm telephoto — a small telescope actually, the gear shown below. It’s what I was using most of this past week to shoot the Australian southern sky.

Borg 77mm Astrograph in Australia

This is some of my Oz gear, the equipment (except for the camera and autoguider on top) that stays in Australia for use every year or two. The mount is an Astro-Physics 400 and the scope is the Borg 77mm f/4 astrograph. I used it for the close-up photo.

The gear all worked great this time. I’ll have more photos to post shortly as my connection allows. Tonight, I am at the Parkes Radio Observatory where the internet connection is as good as it gets!

— Alan, April 4, 2014 / © 2014 Alan Dyer







Centre of the Galaxy Rising


Galactic Centre Rising from Australia #2 (15mm 60Da)

The centre of our Galaxy rises above the gum trees of Australia.

This was the scene at 3 a.m. this week at our OzSky star party, as the stars of Scorpius and Sagittarius rise into the eastern sky, a magnificent view of the bright core of the Milky Way rising into view.

The image shows the intricate lacework of dark dust that lines the Milky Way – the stardust of which we are made. The bright star at upper left is Antares, the heart of the Scorpion.

This is one of the views you travel to the southern hemisphere to see. It is an unforgettable sight, one of the best the sky has to offer.

– Alan, April 2, 2014 / © 2014 Alan Dyer



Observing under the Southern Stars


OzSky Star Safari Panorama #2 (March 2014)

The Milky Way arches over our observing field at the OzSky star party in Australia.

What an amazing few nights it has been. We’ve enjoyed several clear nights under the fabulous southern Milky Way. About 40 people from around the world have had access to telescopes from 14-inch to 30-inch aperture to explore the wonders of the southern sky from a dark site near Coonabarabran, New South Wales.

I’ve seen lifetime-best views of the Tarantula Nebula, the Carina Nebula, the Horsehead Nebula, the Omega Centauri cluster, and on and on! But the views of Mars have been incredible, the best I’ve seen the planet in a decade as it is now close to Earth and high in our southern sky.

The panorama above is a stitch of 6 untracked segments taken with a Canon 60Da and 8mm fish-eye lens. Each segment is a 60-second exposure at ISO 3200.

The 360° panorama takes in the Milky Way from Canis Major setting at right, over to Scorpius and Sagittarius and the centre of the Galaxy rising at left. At top centre is the wonderful Carina and Crux area. The two Magellanic Clouds are just above the trees at centre.

At upper left is Mars, and just to the left of it is a diffuse glow – the Gegenschein, sunlight reflected of comet dust in the direction opposite the Sun. Mars is near that point now. You can just see a faint band running from the Gegenschein to the Milky Way — the Zodiacal Band of comet dust.

Observer & Telescope at OzSky Star Party #4 (March 2014)

Here, one of our observers takes in a view through a 24-inch reflector telescope under the stars of the Southern Cross, the pattern in the Milky Way behind him.

The nights have been warm and wonderful, though a little damp and dewy after midnight. However, rain is in the forecast again, a welcome relief for most local residents who want the rain. They can have it now. We’re happy!

– Alan, April 2, 2014 / © 2014 Alan Dyer

The Milky Way on an Australian Morning


Southern Milky Way in the Morning (March 29, 2014)The Milky Way arches across the pre-dawn sky on a morning in Australia.

This was the view this morning, Saturday, March 29, at about 4:00 a.m. from my observing site near Coonabarabran, Australia. What a sight! The Milky Way extends from Aquila, in our northern sky at left, all the way across the heavens to Crux and Carina, in the southern sky at right. Just left of centre high in the south lies the bright centre of the Galaxy, in Sagittarius and Scorpius.

My ultrawide-angle image frames the “Dark Emu,” made of dark lanes and dust clouds in the Milky Way and prominent in aboriginal sky lore in Australia. His head is the Coal Sack at upper right, his neck the curving dust lane from Alpha Centauri to Scorpius right of centre, and his tail and feet are in the dust lanes left of the galactic centre on the left side of the image. He extends all the way across the sky.

Venus is just coming over the gum trees at lower left. The glow of zodiacal light – sunlight reflected off comet dust in the inner solar system – extends up from Venus to the Milky Way.

After three days of rain – cheered by the residents here! – the skies have cleared and the big telescopes have all arrived for our star party this week. It should be a superb week of stargazing, off to a great start with this view in the Australian dawn.

— Alan, March 29, 2014 / © 2014 Alan Dyer



The Milky Way at Solstice


Centre of Galaxy on Horizon (June 9, 2013)

The centre of the Galaxy culminates over a starlit landscape on a night near the summer solstice.

This was last weekend, on the same night I took the images of the aurora and noctilucent clouds featured in the previous two blog posts. But toward the end of the shoot, I turned south to capture this scene, of the Milky Way over a grassy prairie field.

The landscape is lit only by starlight and by the glow of twilight and aurora to the north.

In the sky, the constellations of Scorpius and Sagittarius are peaking as high as they get for me in southern Alberta. The red giant star Antares is to the right while the bright star clouds toward the centre of our Galaxy are just left of centre. The sky is not dark because of the glow of perpetual twilight at this time of year near solstice.

Deep sky fans will note that the star cluster M7, the southernmost Messier object, is just clearing the horizon.

Remarkably, this is a mere 15 second exposure, at ISO 1600 but with the 24mm lens wide open at f/1.4. Normally I wouldn’t shoot at that wide an aperture as the images look too distorted at the corners of the frame. But for this shot I used the Canon 60Da camera – its cropped-frame sensor records only the central area of what the lens projects so it crops out the nasty stuff at the corners of the frame that would certainly have been detracting had I used the full-frame camera.

But shooting at f/1.4 allowed even this quickie 15-second shot to grab lots of detail in the Milky Way.

– Alan, June 14, 2013 / © 2013 Alan Dyer



Scorpius Rising on the Prairies


Sagittarius and Scorpius on the Horizon (50mm 5DII)

Scorpius and the star clouds of the Milky Way skim along the southern horizon on the western Canadian prairie.

Scorpius crawls along the horizon at right, with dark lanes of dust converging onto yellowish Antares. Just left of centre a dark horse prances above the treetops. At lower left shines the pink Lagoon Nebula.

With its intricate mix of dark dust lanes and bright star clouds this is the richest region of the Milky Way. It marks the direction toward the centre of our Galaxy. Pity it lies so low in our sky from here in western Canada, at a latitude of 50° North. Compare this view to what I saw two months ago from New Mexico and you can see the advantage of a southerly latitude for any lovers of the Milky Way.

However, I was lucky to get this shot, taken last weekend during the only decent time of the year when I can see Scorpius in a dark sky from my prairie home. The night was very clear, allowing a clean shot to the southern horizon.

– Alan, May 9, 2013 / © 2013 Alan Dyer

The Magnificent Milky Way


Sagittarius & Scorpius Over Adobe House (35mm 5DII)

What an amazing area of sky – the centre of the Galaxy hovering over the Earth below.

This was the scene two mornings ago, on our last clear night in New Mexico. This is what’s in the morning sky now and in the evening sky later in July and August. This is the area around Scorpius and Sagittarius and their rich star clouds toward the centre of the Milky Way.

It looks like a scene from an alien planet. But it’s here on Earth, gazing thousands of lights years toward the galactic core.

Enjoy!

– Alan, March 16, 2013 / © 2013 Alan Dyer





Celestial Scorpion in the Desert


Scorpius over Adobe House (35mm 5DII)

This is one of the few constellations that looks like what it is supposed to be – a desert-dwelling scorpion.

This is Scorpius in his native habitat of the desert. Here, from the latitude of southern New Mexico, he is standing on end, his claws at top, his curving tail and stinger at bottom.

The bright yellow star is Antares, the heart of the scorpion, embedded in a colourful mix of magenta, yellow and blue nebulas. Scattered along the Milky Way in the tail of the scorpion you can see several magenta emission nebulas shining by the combined red and blue light of hydrogen atoms.

What I love about this area of sky is the lacework of dark foreground nebulas, and the contrast between the bright star clouds and dark lanes of stardust. At centre left is the Dark Horse, the darkest part of which also carries the name Pipe Nebula.

I shot this image this morning at about 5 a.m, in the hour before the sky brightened with dawn twilight. This is a stack of seven 3-minute exposures with a 35mm lens, including two exposures taken through a diffusion filter to add the accentuated star glows. The ground details come from just one of the exposures.

As it’s been all week, the location is the Painted Pony Resort in southwest New Mexico.

– Alan, March 15, 2013 / © 2013 Alan Dyer

Sagittarius and Scorpius Rising


Sagittarius & Scorpius Rising (24mm 5DII)

This is the view from early this morning as the centre of the Milky Way rises above the desert landscape of New Mexico.

Sagittarius (at centre) and Scorpius (at right) contain the rich starfields of the galactic core. To the eye this scene looks as if bright clouds are moving in to hide the stars, but in fact the glows are stars – clouds of stars forming the glowing bulge of the galactic core. Superimposed on the glowing core are lanes of dark interstellar dust, such as the silhouette of the Dark Horse prancing at centre, with lanes of dust flowing across the sky and converging onto yellow Antares, the heart of Scorpius right of centre.

I shot this before dawn this morning, March 12, from our site in southwest New Mexico. Skies were perfect.

This is a stack of five 5-minute exposures with the 24mm lens at f/2.8. A sixth exposure taken through a diffusion filter added the star glows to accentuate the bright stars and their colours. The foreground is from one exposure and has been processed to bring out the details, here lit only by starlight.

– Alan, March 12, 2013 / © 2013 Alan Dyer



The Natural Naked-Eye Milky Way


Centre of the Milky Way Panorama (2011)

In this image I’ve tried to render the Milky Way in a view that simulates what you see with your unaided eyes.

The result is a celestial portrait in subtle shades of black and white.

This is a photo mosaic, but processed contrary to the usual methods – eliminating colour rather than enhancing it, and reducing contrast rather than boosting it. The result is a view that I think quite nicely matches what your eyes see, though certainly from a dark site. And in this case, you would need to be in the southern hemisphere to see this sweep of the Milky Way, from Aquila at left, to the Southern Cross at right, with the bright star clouds around the centre of the Galaxy in Sagittarius and Scorpius in the middle.

I’ve removed colours except for the muted colours of stars. And I’ve tried to render the stars with an intensity and dynamic range that the eye sees but that is often lost in long exposures.

The dark lanes of dust seen here really do look like this under dark skies. The nearby Coal Sack next to the Southern Cross does look a little darker than the rest of the sky. This view also captures another effect you can see in the real sky – the brighter sky below the Milky Way plane beneath Sagittarius and Aquila – there are more stars there, which make the background sky brighter than above the Milky Way plane (along the top of the photo) where the sky is permeated by dark obscuring dust.

This scene also frames the “dark Emu” – the shape drawn in the dark lanes that looks like a flightless emu in the sky. It’s an important “constellation” in Aboriginal mythology in Australia. The emu’s head is the Coal Sack at far right, her neck the long dark lane curving up through Centaurus and Lupus, and her tail the dark lanes at left in Ophiuchus, Scutum and Aquila.

I shot the original images for this panoramic mosaic in Chile in May 2011. You can see the full colour version in my “Milky Way Mosaic” post from 2011. The colours are wonderful. But there’s something enthralling about “capturing” the view more as your eyes – and mind – remember it.

– Alan, February 3, 2013 / © 2013 Alan Dyer

Milky Way Mosaic


Centre of the Milky Way Panorama (2011)

It’s taken me a few months to get around to the task, but at last! — my mosaic of the Milky Way I shot in Chile back in May.

The panorama is made up of 6 frames, stitched and blended together, extending from Crux, the Southern Cross (at right) to Aquila the eagle (at left) — a sweep of the Milky Way from Acrux to Altair! The mosaic is centred on the core of the Galaxy in Sagittarius and Scorpius.

Panoramas like this allow you to step back a distance and take in the big picture:

— You can see the large-scale structure of the dust clouds and the odd diagonal sweep of many of the clouds cutting across the plane of the Galaxy. I’ve never heard an explanation of why the dust lanes seem to have that structure and direction. I also see a 3D effect, with the nearby dust clouds hanging in front of and obscuring the bright starclouds of the distant inner spirals arms of our Galaxy.

— Also apparent are the extensive dust clouds at left extending from Ophiuchus (at top) down into Aquila, well below the plane of the Galaxy. Most wide-angle shots of the Milky Way I see tend to process out the subtle brown clouds that extend far off the Galactic plane. And they are brown, not black.

— And what really stands out is the band of bright blue stars from Scorpius (at top centre) to the right above the Milky Way through Lupus, Centaurus then down into Crux. This is a section of Gould’s Belt, a ring of hot blue stars around the sky that runs at an angle of about 20° to the Milky Way. This ring of hot, nearby stars surrounds us in our spiral arm and is thought to be only about 65 million years old, likely caused by some disturbance in our spiral arm which set off a wave of star formation close to us.

— And … as my Australian friends will point out, you can see the entire Dark Emu, made of the dust lanes from the Coal Sack in Crux at right (his head and beak), through the curving lanes in Centaurus (his neck), then sweeping up and over the centre of the Galaxy (his body) then down into Scutum and Aquila (his two feet and his tail).

I took this panorama from the Atacama Lodge in north central Chile, using the Canon 5D MkII and Canon 35mm lens. Each of the 6 segments that went into this pan was itself a stack of 4 x 6 minute exposures, plus a fifth exposure through a soft-focus filter, all at f/4 and ISO 800. The camera was on a Kenko SkyMemo tracking platform. I assembled the pan with Photoshop CS5’s Photomerge command. This is actually only half of the full panorama mosaic, which extends for another 5 segments to the right along the Milky Way to Orion, taking in the entire southern portion of the Milky Way. But this is the best bit!

— Alan, Oct 2, 2011 / Image © 2011 Alan Dyer

Into the Heart of the Scorpion


Here we peer into the heart of Scorpius, to a place where the sky is painted with pastel hues unlike anywhere else in the heavens.

The yellow star at bottom is Antares, the cool supergiant star that marks the heart of the Scorpion. To the right is Messier 4, a globular cluster of thousands of stars. Wrapping the entire field are shrouds of dust, reflecting the yellow light of Antares and the blue light of hotter stars above, such as Rho Ophiuchi at top right. Glowing hydrogen gas clouds add the magenta hues.

The remarkable feature of this field are the dark fingers, clouds of dark interstellar stardust glowing with a dim yellowy-brown hue. In places the clouds become more opaque and intense, blocking any light from background stars. Those clouds must be close by in our galactic spiral arm because few stars lie between us and their dark masses. Estimates put them about 400 light years away.

The entire region is a busy factory of star making, one of the closest to our Sun. Chances are our solar system formed in a similar star factory 5 billion years ago, one that has long since dissolved away and dispersed around the Galaxy.

Like the previous shot, this is a Canon 7D/135mm telephoto image in a stack of six 2-minute exposures, taken from Chile in early May. I find it remarkable that with digital cameras just 2-minute exposures not only bring out the dark nebulas, but actually show them with colour and tonality. In the old days, film shots 20 minutes long only ever showed them as a mass of underexposed and featureless black.

— Alan, June 16, 2011 / Image © 2011 Alan Dyer

Off the Stinger Stars of Scorpius


Off the tail of Scorpius lies one of the great starry regions of the Milky Way. From southern Canada the Scorpion’s Tail barely clears our horizon at this time of year, on June nights. But from farther south, Scorpius crawls high into the sky — and the sky actually gets dark at solstice, so stargazers can see the starclouds of Scorpius in all their glory.

At right, the blue stars mark the “stinger” at the end of the Scorpion’s tail. The brightest one, called Shaula, or Lambda Scorpii, is a hot blue giant star some 10,000 times more luminous than our own modest Sun. It is also a triple star, with another luminous blue star orbiting it, plus a third odd mystery star thought to be either a neutron star or perhaps a young proto-object still in the process of forming a proper “main-sequence” normal star.

To the left lie two prominent clusters of stars: at top the Butterfly Cluster (a.k.a. Messier 6), a bright group of stars sitting amid a dark bay of dust. Below it, almost lost in the stars, is Ptolemy’s Cluster (a.k.a. Messier 7), that is an obvious sight to the unaided eye – so obvious the Greek astronomer Ptolemy catalogued it in 130 AD. Several other star clusters pepper the field.

This telephoto lens shot frames the field as binoculars would show it. I took this from Chile in early May, using the Canon 7D and 135mm lens, for a stack of six 2-minute exposures at f/2.8 and ISO 1250.

— Alan, June 16, 2011 / Image © 2011 Alan Dyer





The Galactic Cathedral


We’re on our last full day in Chile, packing up and sorting out. I’ll finish off my Chile blog series with this parting shot — the entire southern Milky Way from horizon to horizon.

In this view, we’re looking straight up, with the horizon at the edges of the frame of the 15mm fish-eye lens. The glowing starclouds of Sagittarius and Scorpius, seen in close up in the previous blog post, are in the centre of the frame. The Southern Cross is at far right, the Northern Cross at far left.

This scene is a superb way to end a night of southern sky stargazing – just lying back and looking up at the entire panorama of the Galaxy. You really do get the sense that we are indeed living at the edge of the Galaxy, looking off into its bright core, and with its spiral arms wrapping around us.

It’s a galactic cathedral of stars.

– Alan, May 7, 2011 / Image  © 2011 Alan Dyer

The Starfields of Sagittarius and Scorpius


I can’t get enough of this region of sky. I can and do shoot this with every lens I have and with all kinds of framing (horizontally, vertically, or at a rakish angle, like here) and it always looks great.

These are the rich and stunning starfields toward the centre of the Milky Way in Sagittarius (bottom) and Scorpius (at top). Look for the pinkish nebulas dotted along the Milky Way, the bright starclouds, and the dark lanes of interstellar dust. It’s all part of the galactic recycling program that our Milky Way participates in, as stars explode, cast off dust and gas, which then clump into glowing nebulas and form new generations of stars.

I took this shot about 5 a.m. a couple of mornings ago, with this area directly overhead. It’s a stack of six 3-minute exposures with the 35mm lens and Canon 5D MkII camera. I took some shots through a soft focus filter to add the star glows.

– Alan, May 7, 2011 / Image © 2011 Alan Dyer

Toward the Centre of the Galaxy


This is without a doubt the most spectacular area of sky. Here we’re looking toward the centre of our Galaxy, toward the starfields of Scorpius (at right) and Sagittarius (bottom centre). The field is a riot of stars, dark lanes of dust, and patches of glowing red nebulas.

It is wonderful experience – wonder-filled! – just to lie back and scan these constellations with binoculars or a wide-field telescope. One outstanding feature are the parallel bands of dark dust that seem to form the shape of a dark prancing horse in the Milky Way.

The brightest area of the Milky Way here is the Sagittarius Starcloud, and marks the direction of the centre of our Galaxy. From here in Chile where I took this shot, this region of sky passes directly overhead, making it more prominent than at northern latitudes where the galactic core is often lost in horizon haze.

This image is a stack of four 6-minute exposures at f/4 with the 35mm lens and Canon 5D MkII camera. For one of the exposures I shot through a special soft-focus filter to add the fuzzy star glows that make it easier to see the outline of the constellations. The filter also emphasizes the colours of the stars.

The image is a segment of a 12-section panorama I shot all along the Milky Way from dusk to dawn.

– Alan, May 3, 2011 / Image © 2011 Alan Dyer

Entangled in Dark Dust


This is a star cluster in Scorpius called NGC 6124 – it doesn’t have a name, to the best of my knowledge. But a good one might be the “Dark River Cluster.”

I’ve shot lots of stuff along the Milky Way on my various trips to the southern hemisphere, but this field was a pleasant new surprise. While I had photographed this star cluster before, previous portraits had been extreme closeups. I had not shot it with a wide field like this.

The field here takes in about the same area of sky as binoculars. One of my projects on this current trip to Chile has been to shoot binocular fields like this. And it’s a good one. The cluster is a little off the beaten track in Scorpius and tends to be ignored. But its position entangled with lanes of dark nebulosity makes it a wonderful contrast of stars and darkness.

The dark lanes are obscuring dust in the foreground, hiding the light of distant stars in the Milky Way. The cluster itself is about 18,000 light years away, quite a distance for a star cluster, and putting it a good portion of the way toward the centre of the Galaxy.

For this shot I used the Canon 7D camera and 135mm telephoto, for a stack of six 2-minute exposures at ISO 800 and f/2.8.

– Alan, May 3, 2011 / Image © 2011 Alan Dyer

Galaxyrise


In the southern hemisphere sky we are treated to the stunning sight of the centre of the Galaxy rising each night, as the starfields of Scorpius and Sagittarius come up over the eastern horizon. In this shot, taken last night (May 2/3), we see the Milky Way’s heart rising behind some of the robotic, remotely-controlled domes and telescopes at the Atacama Lodge in Chile. Only the centre dome is operating, taking images or data under the command of someone half a world away.

Amazing technology to be sure, but … that robotic observer misses the experience of standing under the Milky Way, watching its heart rise over the Andes and swing overhead through the night. The Milky Way is so bright it lights the ground, as you can see here.

Last night our little group of 7 Canadian observers had a fantastic time exploring the southern sky with several telescopes, including an 18-inch reflector set up for us by lodge owner Alain Maury. With the help of a couple of wide-angle eyepieces we saw wonderful views of the Vela Supernova Remnant, dark nebulas in the Milky Way, and showpiece targets like Omega Centauri and the Tarantula Nebula – the list goes on! And will again tonight, as we compile another “hit-list” of targets to find tonight.

For this shot, I used the Canon 7D camera, a 15mm lens, and ISO 2500 for a 40 second exposure at f/2.8. This is one of about 500 frames taken for a time-lapse movie of “Galaxyrise.”

– Alan, May 3, 2011 / Image © 2011 Alan Dyer
