Mars and Jupiter in the Morning


Jupiter and Mars at Dawn

Mars and Jupiter are meeting up in the morning sky. Soon they’ll be joined by the Moon.

Here’s a heads up for one of the best planet conjunctions of the year. Mars and Jupiter are now close together in the dawn sky to the south, and getting closer!

Above is the actual view on the morning of January 4, with Jupiter the brightest of a trio of objects. Mars is reddish and in the middle. The object at right is the star Alpha Librae, also known as Zubenelgenubi in Libra.

Jan 6 Morning Sky
Looking south-southeast on January 6

As shown in the simulation above, on the morning of January 6 Mars and Jupiter will be only 1/3rd of a degree apart (20 arc minutes), so close that dimmer Mars might not be obvious to the naked eye next to bright Jupiter. But use binoculars to show the planet pair.

The next morning, on January 7, they will appear almost as close, as Jupiter climbs higher past Mars.

Jan 11 Morning Sky
Looking south-southeast on January 11

As shown here, on the morning of January 11 the waning crescent Moon will sit only 4 degrees from the planet pair, with all three worlds gathered close enough for binoculars to frame the scene.

With sunrise coming late on winter mornings, it doesn’t take an early rise to take in the dawn scene. Make a note to take a look about 6:30 to 7:00 a.m. over the next week.


POSTSCRIPT added January 6:

Here’s the real scene from the morning of January 6, with Mars and Jupiter just 16 arc minutes apart, very close but still easy to distinguish  with the naked eye. Jupiter did not overwhelm Mars.

Jupiter and Mars in Conjunction at Dawn

Thanks and Clear skies!

— Alan, January 4, 2018 / © 2018 Alan Dyer / amazingsky.com

Dawn Sky Delights


Aldebaran About to be Occulted by the Moon

It was one of those mornings when the sky was full of wonder.

After days and nights of smoke from unfortunate fires burning not far away, including in my favourite national park of Waterton Lakes, the sky cleared enough this morning, September 12, to reveal some fine sights.

At 6 a.m. the waning gibbous Moon passed in front of the star Aldebaran in Taurus. It is performing many such occultations of Aldebaran this year, but most aren’t well seen from any one location. This one was ideal, right from my backyard.

The lead image is a “high dynamic range” stack of several exposures showing the waning Moon and star set in some high haze adding the sky colours.

The star winked out behind the Moon’s bright limb as the Moon advanced from right to left (west to east) against the background sky.

Occultation of Aldebaran
Aldebaran nearing the limb of the Moon.
This shows a composite sequence, with images of the star taken every four minutes blended with a single image of the Moon. While it looks like the star is moving, it is really the Moon that is edging closer to Aldebaran.

The star reappeared from behind the dark limb of the Moon, but five minutes after sunrise, with the Moon in a bright blue sky. Still, the star stood out nicely in binoculars and in the telescope for this view.

Aldebaran Near the Moon in Day Sky
Aldebaran off the dark limb of the Moon.
Aldebaran is the point of light at right, just off the invisible edge of the Moon.

I shot stills and video, and compiled them into this short video.

Enlarge it to full screen to view it properly.

Meanwhile, over to the east the twilight sky was awash in planets.

Rocky Planets at Dawn with Labels (Sept. 12, 2017)
The line of dawn planets, with labels.
All the three inner terrestrial worlds were there: Venus, at top, Mercury below Regulus, and Mars lowest of the trio. Of course, a fourth terrestrial world is in the photo, too – Earth!

Mercury was at its greatest western elongation this morning, placing it as far from the Sun and as high in the sky as it gets, with this autumn appearance the best of 2017 for a morning showing for Mercury. Even so, you can see how Mercury is always low and easy to miss. However, this morning it was obvious to the naked eye.

Mars and Mercury will be in close conjunction at dawn on the morning of September 16.

Rocky Planets at Dawn (Sept. 12, 2017)

It was a fine morning to be up early and enjoy the solar system show.

— Alan, September 12, 2017 / © 2017 Alan Dyer / amazingsky.com



Venus and the Comet


Comet Catalina near Venus (Dec 9, 2015)

Comet Catalina sports two tails as it moves past Venus in the dawn sky.

This was the view this morning, December 9, from my site in Arizona, of Comet Catalina near Venus in the dawn sky. This is a telephoto lens shot that provides a view similar in size to what binoculars show.

However, the blue ion tail visible here stretching back several degrees is mostly a photographic target. Visually, just Catalina’s short, stubby dust tail at lower right is obvious.

The ion tail points away from the Sun, while the dust tail extends along the comet’s orbit, showing where the comet has been.

The view, both visually and photographically, of the comet will improve as it climbs higher into the eastern morning sky and as it moves away from the glare of Venus. The Moon is also now gone from the dawn, at least for the next couple of weeks.

The comet is dimmer than expected but should at least maintain this brightness for the next month or so.

Technical:

This is a stack of 5 x 90-second exposures, taken with the 135mm telephoto and 1.4x extender for a focal length of 190mm, at f/2.8 and with the Canon 5D MkII at ISO 1600, tracked on the iOptron Sky-Tracker. Two other exposures, of 15s and 1s, were blended in with luminosity masks to reduce the glare of Venus to a smaller size.

— Alan, December 9, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Comets, Conjunctions, and Occultations, Oh My!


The Moon, Venus and Comet Catalina

What a morning of sky sights, both before dawn and after sunrise.

December 7 – This was the prime day I came to Arizona to enjoy, to be better assured of clear skies. As it turned out this will likely be the cloudiest day of the week here, but skies were clear enough for a fine view of a conjunction and an occultation. The comet was a bonus.

Waning Moon and Venus Rising in Conjunction
This is a stack of 5 exposures: 30, 8, 2, 0.5 and 1/8s, blended with luminosity masks as HDR would not blend images with such a large range of brightness and content, with the shortest exposures having almost no content execept for two bright objects! The camera was on the iOptron Sky-Tracker to follow the sky and keep the sky targets stationary and aligned, thus the blurred foreground. All with the 135mm lens at f/2.8 and Canon 6D at ISO 400.

At 4 a.m. the waning crescent Moon rose accompanied by Venus, as the two worlds appeared in close conjunction in the pre-dawn sky. The view above captures the scene as the Moon and Venus rose over the Peloncillo Mountains of New Mexico. Comet Catalina is in this scene but barely visible.

The Moon, Venus and Comet Catalina
This is a stack of 6 exposures: 30, 8, 2, 0.5, 1/8s and 1/30s, blended with luminosity masks as HDR would not blend images with such a large range of brightness and content, with the shortest exposures having almost no content execept for two bright objects! The camera was on the iOptron Sky-Tracker to follow the sky and keep the sky targets stationary and aligned. All with the 135mm lens at f/2.8 and Canon 6D at ISO 800.

An hour or so later, with the Moon and Venus higher and with skies a little less cloudy, I was able to capture this scene, above, that included Comet Catalina, as a tiny blue dot next to Venus and the Moon. But if I hadn’t labeled it, you wouldn’t know it was there! The comet is proving to be less wonderful than anticipated, and any cloud dims the view even more.

I had hoped for a superb scene of a bright comet next to the two brightest objects in the night sky. But comets do what comets do — surprise people with unexpected brightness (as Comet Lovejoy did last January) or with disappointing dimness … or by disappearing altogether, as Comet ISON did two years ago. I came here in December 2013, to this same location on the Arizona-New Mexico border, to catch ISON but no luck there at all!

Moon & Venus Conjunction at Sunrise (Dec 7, 2015)
This is a stack of 7 exposures from 10 seconds to 0.3 seconds at 1 stop intervals and blended with luminosity masks, to compress the huge range in brightness from the bright Moon and Venus, plus horizon sky, and the darker sky and sunrise clouds. All with the 35mm lens and Canon 6D.

Regardless of the comet, the conjunction of the Moon and Venus was stunning, about as good as such events get. Here’s the view, above, an hour later again, with the eastern sky brightening in the dawn twilight. The only thing that would have made this event even more spectacular is if the Moon had actually covered up Venus in this twilight sky. Not quite.

Daytime Occultation of Venus (Dec 7, 2015)
The occultation of Venus by the waning crescent Moon in the daytime on Monday, December 7 at 9:30 am local time. This is just about 3 minutes before the actual occultation as the advancing Moon is about to cover Venus on the bright limb of the Moon. This is a frame from a 100-frame time lapse. Unfortunately, as I shot this on my trip to Arizona, I did not have more focal length than the 135mm and 1.4x extender used here.

For the occultation itself, we had to wait until well after sunrise for an event in the blue daytime sky, at 9:30 a.m. local time.

All of North America got to see this fairly rare occultation of Venus by the Moon, albeit in the daytime. Nevertheless, the two objects are so bright, this was visible to the unaided eye, even with some cloud about. In binoculars it was wonderful.

To shoot it, all I had was a telephoto lens, so the image scale doesn’t do the event justice. But the image above provides a good impression of the binocular view, with Venus as a brilliant jewel on the “ring” of the Moon.

— Alan, December 7, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Circles and Lines in the Dawn Sky


A classic 22° ice crystal halo around the waning crescent Moon, here overexposed, with the Moon between Jupiter and Mars in the morning sky on December 5, 2015. Seeing a halo around a crescent Moon is somewhat rare as they usually require the brighter light of the Full Moon. Venus is the brightest object at bottom closest to the horizon. The three planets, along with the stars Spica (above Venus) and Regulus (at top of frame) define the line of the ecliptic here in the dawn late autumn / early winter sky. I captured this scene from southeast Arizona near the Arizona Sky Village at Portal. This is a stack of 4 exposures from long to short (8s to 1/2s) to encompass the great range in brightness and not overexpose the crescent Moon too much. Images were layered in Photoshop and masked with luminosity masks. Automatic HDR techniques did not work well as the shortest image was too dark for ACR to find content to register in Merge ot HDR, and in Photoshop the HDR Pro module left visible edge artifacts. The camera was on the iOptron Sky Tracker to follow the sky and register the sky for all the exposures, thus the slightly blurred ground. Taken with the Canon 6D and 15mm full-frame fish-eye lens.

Cloud hid Comet Catalina but added a halo around the waning Moon, intersected by the line of the ecliptic.

I’m in Arizona, just inside the state line with New Mexico, on a quest to shoot Comet Catalina at dawn. Clouds prevented any view of the faint comet this morning but provided a fine consolation prize.

The waning crescent Moon was surrounded by an ice crystal halo, a rare sight around a thin Moon. The Moon was between Mars and Jupiter, heading toward a conjunction with Venus, below, on December 7.

The line of Venus, Mars, the Moon, and Jupiter, plus the stars Spica and Regulus defined the line of the ecliptic beautifully in the pre-dawn sky.

A classic 22° ice crystal halo around the waning crescent Moon, here overexposed, with the Moon between Jupiter and Mars in the morning sky on December 5, 2015. Seeing a halo around a crescent Moon is somewhat rare as they usually require the brighter light of the Full Moon. Venus is the brightest object at bottom closest to the horizon. The three planets, along with the stars Spica (above Venus) and Regulus (at top of frame) define the line of the ecliptic here in the dawn late autumn / early winter sky. I captured this scene from southeast Arizona near the Arizona Sky Village at Portal. This is a stack of 4 exposures from long to short (8s to 1/2s) to encompass the great range in brightness and not overexpose the crescent Moon too much. Images were layered in Photoshop and masked with luminosity masks. Automatic HDR techniques did not work well as the shortest image was too dark for ACR to find content to register in Merge ot HDR, and in Photoshop the HDR Pro module left visible edge artifacts. The camera was on the iOptron Sky Tracker to follow the sky and register the sky for all the exposures, thus the slightly blurred ground. Taken with the Canon 6D and 15mm full-frame fish-eye lens.
This is a stack of 4 exposures from long to short (8s to 1/2s) to encompass the great range in brightness and not overexpose the crescent Moon too much. Images were layered in Photoshop and masked with luminosity masks. Automatic HDR techniques did not work well as the shortest image was too dark for ACR to find content to register in Merge ot HDR, and in Photoshop the HDR Pro module left visible edge artifacts.
The camera was on the iOptron Sky Tracker to follow the sky and register the sky for all the exposures, thus the slightly blurred ground. Taken with the Canon 6D and 15mm full-frame fish-eye lens.

It was a show of circles and lines, real and imagined, in the morning sky.

With luck, clouds will clear to reveal Comet Catalina, which is likely fainter and less spectacular than hoped. But such is the way of comets. Regardless of what the comet does, it is a good time to be in the desert southwest, typing this blog on a sunny front porch under blue desert skies.

— Alan, December 5, 2015 / © 2015 Alan Dyer / www.amazingsky.com



The Visible Ecliptic at Dawn


Venus (brightest), with dim Mars above it, then bright Jupiter, in a diagonal line across the dawn sky on November 14, 2015. Regulus and Leo are at top right, Arcturus in Bootes is at left, and Spica in Virgo is just rising at centre. Spica, Venus, Mars, Jupiter and Regulus more or less define the line of the ecliptic in the autumn morning sky here. This is a stack of 4 x 20 second exposures for the ground, to smooth noise, and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1000 and Nikkor 14-24mm lens at f/2.8 and at 14mm

The morning planets are now strung out along the ecliptic, visualizing this line in the sky.

This was the view this morning, November 14, of the three dawn planets lined up along the ecliptic, with the stars Spica and Regulus also defining this imaginary line.

The ecliptic is the Earth’s orbital path around the Sun projected into the sky. So it is along this line that we see the Sun appear to move around the sky over a year. But it is also the path along which we find the seven other major planets – in this case, three of them: Venus, Mars and Jupiter.

These three worlds were clustered together in October, but are now spreading out along the ecliptic, as Venus drops lower but Mars and Jupiter climb higher.

The stars Spica and Regulus also lie along the ecliptic, where the Moon can occasionally pass in front of, or occult, these stars.

So the two stars and three planets are now nicely drawing the ecliptic line for us in the dawn sky. At this time of year, the ecliptic is also steeply angled above the eastern horizon.

The main image above is a stack of 4 x 20 second exposures for the ground, to smooth noise, and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1000 and Nikkor 14-24mm lens at f/2.8 and at 14mm.

Venus (brightest), with dim Mars above it, then bright Jupiter, in a diagonal line across the dawn sky on November 14, 2015, with the Zodiacal Light barely visible in the brightening twilight sky. Arcturus is a left and Spica is just rising at centre. Corvus is just above the treetops at right. Spica, Venus, Mars and Jupiter more or less define the line of the ecliptic in the autumn morning sky here. This is a stack of 4 x 20 second exposures for the ground, to smooth noise, and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1000 and Nikkor 14-24mm lens at f/2.8 and at 24mm
Venus (brightest), with dim Mars above it, then bright Jupiter, in a diagonal line across the dawn sky on November 14, 2015, with the Zodiacal Light barely visible in the brightening twilight sky. Arcturus is a left and Spica is just rising at centre. Corvus is just above the treetops at right. Spica, Venus, Mars and Jupiter more or less define the line of the ecliptic in the autumn morning sky here. This is a stack of 4 x 20 second exposures for the ground, to smooth noise, and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1000 and Nikkor 14-24mm lens at f/2.8 and at 24mm

This image just above is with the same gear but with the lens at the 24mm setting to more tightly frame the planets.

Meanwhile, on the other side of the sky at dawn, Orion and his winter sky friends were setting into the west (image below).

Orion and the winter constellations setting over the old Farmhouse at home, in the dawn twilight on the morning of November 14, 2015. Canis Major and Sirius are at left; Taurus and Aldebaran and the Pleiades are at right. Procyon is at upper left.  This is a stack of 4 x 20 second exposoures for the ground to smooth noise and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1600 and 14-24mm Nikkor zoom lens at f/2.8.
Orion and the winter constellations setting over the old Farmhouse at home, in the dawn twilight on the morning of November 14, 2015. Canis Major and Sirius are at left; Taurus and Aldebaran and the Pleiades are at right. Procyon is at upper left. This is a stack of 4 x 20 second exposoures for the ground to smooth noise and one 20-second exposure for the sky, all with the Nikon D810a at ISO 1600 and 14-24mm Nikkor zoom lens at f/2.8.

All the images here are shot with the Nikon D810a camera and the amazing Nikkor 14-24mm lens, two items in hand this month for testing and review. A thorough test will appear in future blogs.

Of course, as wonderful as the gear is, it cannot extract the ecliptic line and labels from the sky – those are added in Photoshop!

– Alan, November 14, 2015 / © 2015 Alan Dyer / amazingsky.com

Three Planets and the Moon in the Morning


The waning crescent Moon below Jupiter, with that pair of worlds above the pairing of Venus (bright) and red Mars (just above Venus), all in the dawn sky, November 6, 2015.  This is a composite of 4 exposures: 30 seconds for the ground (to bring out detail there), 8 seconds for the sky (short enough to prevent star trailing), and 2 and 1/4 seconds for the Moon itself to prevent it from being totally blown out as a bright blob. All with the Nikon D750 at ISO 1600 and Sigma 24mm Art lens at f/4. Taken from home.

The waning crescent Moon joined the planet trio this morning for a fine sight in the dawn.

This was the scene on November 6 with the waning crescent Moon just below Jupiter, and those two worlds just above the pairing of bright Venus with dim red Mars.

On Saturday, November 7, the waning Moon will sit beside Venus for an even more striking conjunction.

The waning crescent Moon below Jupiter, with that pair of worlds above the pairing of Venus (bright) and red Mars (just above Venus), all in the dawn sky in Leo, November 6, 2015. The stars of Leo are above, including Regulus. This is a composite of 4 exposures: 15 seconds for the ground (to bring out detail there), 4 seconds for the sky (short enough to prevent star trailing), and 1 and 1/4 seconds for the Moon itself to prevent it from being totally blown out as a bright blob. All with the Nikon D750 at ISO 2000 and Sigma 24mm Art lens at f/4.5. Taken from home.
The waning crescent Moon below Jupiter, with that pair of worlds above the pairing of Venus (bright) and red Mars (just above Venus), all in the dawn sky in Leo, November 6, 2015. The stars of Leo are above, including Regulus.
This is a composite of 4 exposures: 15 seconds for the ground (to bring out detail there), 4 seconds for the sky (short enough to prevent star trailing), and 1 and 1/4 seconds for the Moon itself to prevent it from being totally blown out as a bright blob. All with the Nikon D750 at ISO 2000 and Sigma 24mm Art lens at f/4.5. Taken from home.

This meeting of the Moon with the planet trio more or less concludes the superb series of dawn sky conjunctions we’ve been enjoying over the last month.

The planets remain in the morning sky but now go their own ways as Mars and Jupiter climb higher, while Venus drops lower.

— Alan, November 6, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Triangle of Planets in the Twilight


Mars, Venus and Jupiter (in that order from top to bottom) in a triangle, in conjunction, at an old farmstead near Vulcan, Alberta, in the morning twilight, October 28, 2015. Illumination is from the nearly Full Hunter’s Moon in the west. The trio of planets were in Leo in a fine conjunction not to be repeated until November 21, 2111. Almost all of Leo is visible here, with Regulus, the constellation’s brightest star, just to the right of the windmill blades at top. This is a stack of 6 exposures for the ground, mean combined to smooth noise, and one exposure for the sky, all  10 seconds at f/4 and ISO 800 with the Canon 6D and Canon 24mm lens.

This was the trio of planets at their best in the morning sky.

On the morning of October 28, Mars, Venus and Jupiter formed a neat isosceles triangle in the twilight. Venus, the brightest, was in the middle, with Mars below and Jupiter above. The grouping shone amid the stars of Leo, with its brightest star, Regulus, above the windmill in the lead image above. The rest of Leo lies above the planets.

To capture the scene I drove west at 5 am to a farmstead I had shot at before, in June, to capture Venus and Jupiter, also then in Leo near Regulus, but in the evening sky looking west. Click here for that blog post from mid-June.

This morning, the Moon, just past full as the annual Hunter’s Moon, shone in the west off camera lighting the landscape.

Mars, Venus and Jupiter (in that order from top to bottom) in a triangle, in conjunction, over an old red barn near Vulcan, Alberta, in the morning twilight, October 28, 2015. Illumination is from the nearly Full Hunter’s Moon in the west. The trio of planets were in Leo in a fine conjunction not to be repeated until November 21, 2111.  This is a stack of 6 exposures for the ground, mean combined to smooth noise, and one exposure for the sky, all  10 seconds at f/4 and ISO 800 with the Canon 6D and Canon 24mm lens.

The dawn sky colours and the moonlit red barn made for a fine colour contrast.

After today, the planet configuration breaks up, as Venus descends to meet Mars on November 2 and 3, while Jupiter climbs higher. But another great morning sight awaits on November 7 when the waning crescent Moon will shine near the Venus-Mars pairing, with Jupiter above.

The conjunction of Mars, Venus and Jupiter (from bottom to top) in the dawn sky over the misty waters of Lake Macgregor in southern Alberta, on October 28, 2015. This is a single 1/4-second exposure at f/4 and ISO 400 with the Canon 6D and 24mm Canon lens.

On the way home I stopped at fog-bound Lake MacGregor to capture the planets in a brightening dawn sky over the misty waters.

This morning the three planets lay just 4.5 degrees apart, close enough to frame in high-power binoculars.

We won’t see these three planets this close to each other in a darkened sky — as opposed to being so close to the Sun we really can’t see them — until November 21, 2111.

Be sure to catch the dawn show while it lasts!

— Alan, October 28, 2015 / © 2015 Alan Dyer / www.amazingsky.com

A Stunning Gathering of Worlds


The conjunction of Venus (brightest), Jupiter (above Venus) and Mars (dimmer below Venus & Jupiter) looking east in the morning twilight on October 25, 2015, as seen from the west shore of Lake Annette, in Jasper National Park, Alberta. The mountain is the Watchtower. Morning mist covers the lake waters. Haze in the sky adds the natural glows around the planets — no filters were empolyed here. This is a layered stack of 4 images: 10, 5, 2.5 and 1.3-second exposures, with the longer exposure for the ground and the shorter exposures adding the sky to maintain tonal balance between the dark ground and bright sky. All with the 24mm lens and Canon 6D at ISO 400. It was not possible to capture the reflection of the planets in the water as they were too high in the sky.

Skies were clear at dawn this morning for a fabulous view of the rare conjunction of three planets. And I could not have been at a more photogenic site.

This was the view before dawn on October 25, as brilliant Venus and dimmer Jupiter shone just a degree apart in the dawn sky. Mars, much fainter, shines just below the close duo. The three planets could easily be contained in a high power binocular field.

Not until November 2111 will these three planets be this close together again in a darkened sky.

Indeed, Venus could not have been higher, as it is just now reaching its maximum elongation from the Sun, placing it high in the eastern morning sky.

A panorama of roughly 120° showing a star- and planet-filled sky in the dawn twilight over Lake Annette in Jasper National Park, Alberta, on the morning of October 25, 2015.  At left, to the east, are the two bright planets, Venus (brightest) and Jupiter in a close conjunction 1° apart (and here almost merging into one glow), plus reddish Mars below them, all in Leo, with the bright star Regulus above them. Right of centre, to the south, is Orion and Canis Major, with the bright star Sirius low in the south. At upper right are the stars of Taurus, including Aldebaran and the Hyades star cluster. Venus was near greatest elongation on this morning.  No special filter was employed here — the hazy planets and stars and colourful star images comes naturally from a high haze over the sky this morning. It bloats the images of Venus and Jupiter so they almost merge.  The stars are partly reflected in the waters, with rising mist in the distance on the lake. Distant Whistler peak below Orion is lit by lights from the Jasper Townsite. The site is the shore of Lake Annette near the Jasper Park Lodge and site of the annual star party held as part of the Jasper Dark Sky Festival. I shot this scene the morning after the 2015 Festival. This is a panorama of 8 segments, shot with the 24mm lens mounted vertically (portrait), each for 25 seconds at f/2.8 with the Canon 6D at ISO 3200. Stitched with Photoshop, with some vertical scaling to reduce the distortion introduced by the pan mapping process.

I shot from the shores of Lake Annette, site of one of the major events, the Friday star party, at the annual Jasper Dark Sky Festival which just concluded, in Jasper National Park, Alberta. The Festival celebrates the Park’s status as one of the world’s largest Dark Sky Preserves.

The hotels and restaurants were full with stargazers from around the world, making the Festival a huge success, both educationally and financially. I was honoured to be able to present some of the public and school talks.

But this dawn sky was a fine way to end a fabulous weekend of astronomy.

The image above is a panorama in the twilight, sweeping from the planets in the east, to the winter stars and constellations, including iconic Orion, in the south and southwest.

A panorama of roughly 180° showing a star- and planet-filled sky in the pre-dawn hours over Lake Annette in Jasper National Park, Alberta, on the morning of October 25, 2015.  At left, to the east, are the two bright planets, Venus (brightest) and Jupiter in a close conjunction 1° apart (and here almost merging into one glow), plus reddish Mars below them, all in Leo, with the bright star Regulus above them. At centre, to the south, is Orion and Canis Major, with the bright star Sirius low in the south. At upper right are the stars of Taurus, including Aldebaran and the Pleiades star cluster. Venus was near greatest elongation on this morning.  The Milky Way runs vertically at centre, between Sirius and Procyon, the bright star above centre. The faint glow of morning Zodiacal Light rises in a diagonal band at left in the east through the planets and stars of Leo and into Cancer and the Beehive Cluster at top left.  No special filter was employed here — the hazy planets and stars and colourful star images comes naturally from a high haze over the sky this morning. It bloats the images of Venus and Jupiter so they almost merge.  The stars are partly reflected in the waters with wind distorting some of the reflections. Some green airglow appears in the south as well. Distant Whistler peak below Orion is lit by lights from the Jasper Townsite. The site is the shore of Lake Annette near the Jasper Park Lodge and site to the annual star party held as part of the Jasper Dark Sky Festival. I shot this scene the morning after the 2015 Festival. This is a panorama of 12 segments, shot with the 24mm lens mounted vertically (portrait), each for 30 seconds at f/2.8 with the Canon 6D at ISO 3200. Stitched with Photoshop, with some vertical scaling to reduce the distortion introduced by the pan mapping process.

Earlier in the morning, before twilight began to brighten the sky, I shot another even wider panorama from the south shore of the lake.

In this and other photos, high haze adds the glows around the stars and planets naturally. No special effects filters here!

But Venus and Jupiter are so close and bright their images almost merge into one glow.

Brilliant Venus, in conjunction with dimmer Jupiter above, and with even dimmer Mars below, at left here, on the morning of October 25, 2015 when Venus and Jupiter were only 1° apart.  I shot this from Lake Annette in Jasper National Park before the sky started to brighten with dawn twilight. High haze in the sky adds the glows around the stars and planets, in particular the colored halo around Venus. The mountain is the Watchtower. The site is used as the main star party location for the annual Jasper Dark Sky Festival. This is a 30-second exposure at f/2.8 with the 35mm lens and as ISO 1600 with the Canon 6D.

Here they are, with Mars below, shining in the dark sky over the Watchtower peak and over the misty waters of Lake Annette.

Keep an eye on the sky at dawn, as these three worlds will be close to each other for the next few mornings. See my earlier blog for details.

— Alan, October 25, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Four Planets Along the Morning Ecliptic


Four planets in the morning sky, on October 20, 2015, along the ecliptic from bottom to top:  - Mercury (close to the horizon at lower left) - Mars (dim, below Jupiter) - Jupiter (fairly bright at upper right) - Venus (brightest of the four) I shot this from home in southern Alberta. This is a composite stack of 5 exposures from 15 seconds to 1 second to contain the range of brightness from the bright horizon to the dimmer sky up higher. All with the 35mm lens and Canon 6D at ISO 800.

Four planets appear in the dawn sky outlining the morning ecliptic.

This morning, October 20, I was able to capture four planets in the morning sky, arrayed along the ecliptic.

From bottom to top they are: Mercury (just past its point of greatest elongation from the Sun), dim Mars, bright Jupiter, and very bright Venus (just 6 days away from its point of greatest elongation from the Sun). Above Venus is Regulus, in Leo.

I’ve added in the labels and the line of the ecliptic, rising steeply out of the east in the autumn dawn sky.

Of course, there is a fifth unlabelled planet in the scene, quite close in the foreground.

The image below is an unlabeled version.

Four planets in the morning sky, on October 20, 2015, along the ecliptic from bottom to top:  - Mercury (close to the horizon at lower left) - Mars (dim, below Jupiter) - Jupiter (fairly bright at upper right) - Venus (brightest of the four) I shot this from home in southern Alberta. This is a composite stack of 5 exposures from 15 seconds to 1 second to contain the range of brightness from the bright horizon to the dimmer sky up higher. All with the 35mm lens and Canon 6D at ISO 800.

Mercury will be disappearing from view very quickly now as it drops back down toward the Sun.

But over the next week the three higher planets will converge into a tight triangle just 4.5 degrees apart. We won’t see these three planets this close together in a darkened sky until November 2111.

For more information on this week’s dawn sky planet dance see my previous blog entry.

TECHNICAL:
I shot the scene from home in southern Alberta. The image is a composite stack, with manually created masks (not an HDR stack), of 5 exposures, from 15 seconds to 1 second, to contain the range of brightness from the bright horizon to the dimmer star-filled sky higher up. All are with the 35mm lens and Canon 6D at ISO 800.

— Alan, October 20, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Heads Up! — Planet Dance in the Dawn


Oct 17 Dawn Sky

Watch a trio of planets converge in the dawn sky.

You might have already seen Venus shining brightly in the morning sky. And perhaps you’ve seen a slightly less bright object below it. That’s Jupiter.

But there’s a third, even dimmer planet accompanying Venus and Jupiter — reddish Mars. On the morning of Saturday, October 17 (chart above ⬆️) Mars and Jupiter pass just 1/2 degree apart, for a mismatched double “star” at dawn.

The planets put on an even better show in the following 10 days as all three converge to form a tight triangle of worlds in the morning sky.

Oct 23 Dawn Sky

On October 23 ⬆️, Venus, Mars and Jupiter appear in a close grouping just 4.5 degrees apart, close enough to each other to be easily contained in the field of typical binoculars, the circle shown in these charts.

Oct 25 Dawn Sky

Two mornings later, on October 25 ⬆️, Venus and Jupiter are at their closest apparent separation, just 1 degree apart, for a brilliant double “star” in the morning twilight. If you miss this morning, on the next morning, October 24, the two planets appear about the same distance apart as well.

Oct 28 Dawn Sky

By October 28 ⬆️, the three planets have switched positions, as Venus drops lower but Jupiter climbs higher. But they again appear in a triangle, 4.5 degrees wide.

The motion you’re seeing from day to day is due to a combination of the planets’ own orbital motions around the Sun, as well as our planet’s motion.

Keep in mind, the planets aren’t really close together in space. They lie tens, if not hundreds, of millions of kilometres apart. They appear close to each other in our sky because they lie along the same line of sight.

Do try to get up early enough — between 6 a.m. and 6:30 a.m. should do it — to look east to see the changing configuration of planets as they dance at dawn. Binoculars will provide the best view.

This is a rare sight! We won’t see these three planets this close to each other in a darkened sky until November 20, 2111!

— Alan, October 16, 2015 / © 2015 Alan Dyer / www.amazingsky.com

The Moon and Four Planets


The waning crescent Moon, lit by Earthshine, with four planets on the morning of October 9, 2015, with the planets from bottom left to top right: • Mercury, just above the horizon between the low cloud bands, at lower left • Jupiter, bright at centre • Mars, reddish and above Jupiter • Venus, brightest at upper right and in some thin cloud.  The bright star Regulus in Leo is above and to the left of Venus. This is a blend of four exposures: a long 4-second exposure for most of the sky and ground and shorter 2, 1, amd 1/2 second exposures for the bright twilight area and around the Moon and Venus, to prevent those areas fro being blown out. Blending is with masks, not HDR. All with the Canon 6D at ISO 400 and 50mm Sigma lens at f/2.5

The Moon appeared along with four planets in the dawn sky.

The sky was filled with planets this morning, as all four of the closest planets to the Sun appeared along the ecliptic in the morning sky. Plus there’s a fifth planet in the picture – Earth.

Here, the waning crescent Moon, lit by Earthshine, appears with four planets on the morning of October 9, 2015, with the planets from bottom left to top right:

• Mercury, just above the horizon between the low cloud bands, at lower left
• Jupiter, bright at centre
• Mars, reddish and above Jupiter
• Venus, brightest at upper right and in some thin cloud.

The bright star Regulus in Leo is above and to the left of Venus.

The waning crescent Moon, lit by Earthshine, with four planets on the morning of October 9, 2015, with the planets from bottom left to top right: • Mercury, just above the horizon between the low cloud bands, at lower left • Jupiter, bright at centre • Mars, reddish and above Jupiter • Venus, brightest at upper right and in some thin cloud.  The bright star Regulus in Leo is above and to the left of Venus. This is a blend of four exposures: a long 4-second exposure for most of the sky and ground and shorter 2, 1, amd 1/2 second exposures for the bright twilight area and around the Moon and Venus, to prevent those areas fro being blown out. Blending is with masks, not HDR. All with the Canon 6D at ISO 400 and 50mm Sigma lens at f/2.5

Above is an unlabeled version of the image.

TECHNICAL:

It’s a blend of four exposures: a long 4-second exposure for most of the sky and ground, plus shorter 2, 1, and 1/2 second exposures for the bright twilight area and around the Moon and Venus, to prevent those areas from being blown out. Blending is with masks, not HDR. All were shot with the Canon 6D at ISO 400 and 50mm Sigma lens at f/2.5.

– Alan, October 9, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Heads Up! – Dawn Sky Delight


Oct 8 Dawn Planets

Look east this week to see a wonderful conjunction of the waning Moon with three planets in the morning sky.

A great dance of the planets is about to begin in the dawn sky.

Venus, Mars and Jupiter are now all prominent in the eastern sky before sunrise, with Venus by far the brightest. Below it shines slightly dimmer Jupiter. But between those two brightest of planets shines dim red Mars.

The three planets are converging for a mutual close meeting in the third week of October, when from October 23 to 28 the trio of planets will appear within a binocular field of each other.

But this week, with the three planets still spread out along a line, the Moon joins the scene to start the planet dance. It shines near Venus on the morning of October 8 (as shown here). and then near Mars and Jupiter on October 9.

Look east between 5:30 and 6:30 a.m. local time. All the planets are easy to see with unaided eye even in the city, but binoculars will frame the Moon-Venus pairing on October 8 and the Moon-Mars-Jupiter trio on October 9.

– Alan, October 8, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Morning Star, the Milky Way, and the Zodiacal Light


Venus shines brightly, and nearly at its brightest at magnitude -4.7, in the dawn sky on a very frosty morning at 5 am, on September 17, 2015, from home in southern Alberta. Venus appears amid the faint glow of the Zodiacal Light, sometimes called the “False Dawn,” stretching vertically from the dawn horizon in the east, up and to the right, and reaching the Milky Way that runs down the frame from top centre to bottom right. Orion and the winter stars shine in the Milky Way, with Sirius above the trees at lower right. The Beehive Cluster, M44, appears as the small group of stars above Venus. The Pleiades, M45, is at top right. Mars is the brightest object left of Venus, with the bright star Regulus just below it and rising in the east. The stars of the Big Dipper are at far left at the edge of the frame. The sky is beginning to brighten with the real glow of morning.  This is a stack of 4 x 2-minute exposures, tracked and mean combine stacked, for the sky and 2 x 2-minute exposures, untracked and stacked, for the ground to minimize blurring in the starlit ground. The Canon 6D was on the iOptron Sky-Tracker, shooting at ISO 1250 with the 15mm full-frame fish-eye lens at f/3.5. The stacking with a mean combine stack mode smooths noise in both sky and ground.

Venus, now at its brightest as a morning star, shines amid the subtle glow of the Zodiacal Light.

This was the scene this morning, September 17, on a very frosty dawn at 5 a.m. from my backyard in southern Alberta.

Here, Venus shines nearly as bright as it can be, at magnitude -4.7, in the dawn sky as a brilliant “morning star.”

Venus appears amid the faint glow of the Zodiacal Light, sometimes called the “False Dawn,” stretching diagonally from the dawn horizon in the east, up and to the right, and reaching the Milky Way that runs vertically down the frame from top centre to bottom right.

Orion and the winter stars shine in the Milky Way, with Sirius above the trees at lower right.

The Beehive Cluster, M44, appears as the small group of stars above Venus. The Pleiades, M45, is at top right.

Mars is the brightest object left of Venus, with the bright star Regulus just below it and rising in the east. The stars of the Big Dipper are at far left at the edge of the frame.

The sky is beginning to brighten with the real glow of morning. It was a marvellous dawn sky delight.

Technical notes:

This is a stack of 4 x 2-minute exposures, tracked and mean-combine stacked, for the sky and 2 x 2-minute exposures, untracked and stacked, for the ground to minimize blurring in the starlit ground. The Canon 6D was on the iOptron Sky-Tracker, shooting at ISO 1250 with the 15mm full-frame fish-eye lens at f/3.5. The stacking with a mean combine stack mode smooths noise in both sky and ground.

– Alan, September 17, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Heads Up! – Dawn Planet Dance Begins


Sept 10 Moon & Venus

Look east at dawn on September 10 to see the first in a series of planet dances in the dawn sky.

Earlier this year in spring we had Venus and Jupiter blazing in the evening western sky. Now, after a time of retreat behind the Sun, they are emerging to repeat their show together but in the dawn sky.

However, Venus and Jupiter won’t be close together until the end of October. Until then, Venus and Jupiter slowly converge in the dawn sky, but now accompanied by dimmer but redder Mars.

On the morning of September 10, look east before sunrise to see the waning crescent Moon shining between Venus and Mars. Binoculars will frame the Moon and Venus, or the Moon and Mars, but not all three at once.

If your horizon and sky are very clear you might spy Jupiter as well shining down below the trio in the bright morning twilight.

The real dawn dance begins in mid to late October, when first Mars, then Venus passes Jupiter, and all three worlds cluster in a tight triangle in the morning twilight.

— Alan, September 7, 2015 / © 2015 Alan Dyer / www.amazingsky.com

Dawn Conjunction of Venus and Jupiter


Venus & Jupiter Conjunction, with Moon (August 18, 2014)

It was a fine celestial sight to begin the week, as Venus met Jupiter in the dawn sky.

This morning, August 18, Venus and Jupiter appeared just 1/2 degree apart, as close as they’ve appeared to each other since 1999.

The top image shows the wide-angle setting, with Venus and Jupiter tightly paired near the horizon, and the waning Moon above, itself in conjunction with Aldebaran in the Hyades star cluster.

Venus & Jupiter Conjunction Closeup

This zooms into the main event, the Venus-Jupiter pairing, as they were emerging from the horizon haze.

I shot this from home, off the back deck, having little ambition at 5 a.m. to venture any further afield. I had planned to shoot this from Dinosaur Park but had second thoughts on the hour drive there and back!

Waning Moon in the Hyades near Aldebaran

This zooms into the secondary show this morning, the meeting of the waning crescent Moon with the brightest star in Taurus, Aldebaran, and its companion stars in the Hyades star cluster. This is a telephoto lens shot with a fixed camera, no tracking.

Thus begins a fine two weeks of stargazing, weather permitting, as the Moon exits the sky to leave us the summer Milky Way at its best, and dual pairs of planets in the dusk and dawn sky – Mars and Saturn converging in the evening and Venus and Jupiter, now parting ways, in the morning.

– Alan, August 18, 2014 / © 2014 Alan Dyer



Waning Moon in the Sunrise Clouds


Waning Moon at Sunrise (Feb 27, 2014)

The thin waning Moon sits in the red clouds of sunrise on a winter morning.

This was the scene this morning, February 27, just before sunrise when I was able to catch the thin crescent Moon – a waning Moon – amid the sunrise clouds. The Moon just happened to appear in a clearer hole in the clouds, in a blue patch above the pinks and oranges of the clouds. They contrast with the cold blue snow below.

This was a beautiful scene to start the day.

– Alan, February 27, 2014 / © 2014 Alan Dyer



Sundiving Comet ISON – A Last Look


Comet ISON C/2012 S1 (Nov 21, 2013)

Comet ISON performs its dive toward the Sun, caught in the morning twilight.

This was the infamous and much-hyped Comet ISON (C/2012 S1) as it appeared this morning, November 21, 2013, a week before it performs its hairpin turn around the Sun.

The comet was easy to see in binoculars, though the camera picks up a bit more of its faint tail. ISON was much more photogenic a week ago when it was higher in a darker and moonless sky. But this morning I had to contend with bright moonlight from a waning Moon and the brightening dawn. The inset shows a blow up of just the comet.

ISON is dropping rapidly toward the Sun, making this perhaps the last sighting I’ll have of it until it reappears – we hope! – from behind the Sun in early December. If it survives its perihelion passage it might blossom into brilliance … or fade into obscurity. No one knows.

In the photo above, you can see Mercury at left, shining much brighter than ISON. It was brilliant as it rose into the southeast sky, with the elusive planet now about as well-placed as it gets as a “morning star” for us living at northern latitudes.

Comet Lovejoy C/2013 R1 (Nov 21, 2013)

This morning I was able to shoot not one but two comets.

About half an hour before ISON hove into view I aimed the camera up almost overhead toward Ursa Major, to capture Comet Lovejoy (C/2013 R1) as a bright cyan fuzzball with a short tail. Again, the photo brings out the tail – to the eye the comet was obvious in binoculars but appeared as just a fuzzy star.

I took both shots with the same gear: a 135mm telephoto lens on the Canon 5D MkII on an iOptron SkyTracker. The Lovejoy shot is a stack of 5 x 75 second exposures. The ISON shot is a 4-second exposure, with the colours and contrast boosted for prettiness.

This is certainly proving to be a year of comets. It would be nice if just one of them got really bright!

– Alan, November 21, 2013 / © 2013 Alan Dyer



Zodiacal Light – Dawn’s Early Light


Zodiacal Light in Dawn Sky (Oct 2013)

The ghostly glow of comet dust brightens an October dawn.

This is the zodiacal light, as it appeared two mornings ago in the pre-dawn sky from my backyard in southern Alberta. This tapering glow angled up from the horizon is best spotted in the eastern sky on clear and moonless autumn mornings, like this one.

What you are seeing is sunlight reflected off dust left by passing comets in the inner solar system. So while this glow looks like it might originate in our atmosphere it really comes from dust out in interplanetary space.

This subtle glow, often called the “false dawn,” appears in the hour or so before the true dawn begins to brighten the sky too much (its purple light is just starting to light the horizon here).

Also visible here: Sirius at far right, Jupiter above centre, the Beehive star cluster below Jupiter, and Leo rising embedded in the zodiacal light, with Mars just above Regulus, Leo’s brightest star. The planets lie along the zodiacal light because the dust that causes it also lies in the same plane as the orbits of the planets, the ecliptic plane.

I shot this with a 14mm lens for a stack of four 2-minute tracked exposures, but with the horizon coming from just one of the exposures to minimize blurring from the moving camera slowly following the sky.

– Alan, October 10, 2013 / © 2013 Alan Dyer
