waxing Moon – The Amazing Sky

April 9, 2019

The Waxing Moon of Spring

Spring is the season for Earthshine on the waxing Moon.

April 8 was the perfect night for capturing the waxing crescent Moon illuminated both by the Sun and by the Earth.

The phase was a 4-day-old Moon, old enough to be high in the sky, but young enough – i.e. a thin enough crescent – that its bright side didn’t wash out the dark side!

In the lead photo at top, and even in the single-exposure image below taken earlier in a brighter sky, you can see the night side of the Moon faintly glowing a deep blue, and brighter than the background twilight sky.

Four-Day-Old Moon in Blue Twilight — The 4-day-old waxing crescent Moon on April 8, 2019 in a single exposure when the Moon was still in the bright blue twilight. Even so, the faint Earthshine is just becoming visible. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a single 1/8-second exposure.

This, too, is from sunlight, but light that has bounced off the Earth first to then light up the night side of the Moon.

If you were standing on the lunar surface on the night side, the Sun would be below the horizon but your sky would contain a brilliant blue and almost Full Earth lighting your night, much as the Moon lights our Earthly nights. However, Earth is some 80 times brighter in the Moon’s sky than even the Full Moon is in our sky.

Four-Day-Old Moon with Earthshine — The 4-day-old waxing crescent Moon on April 8, 2019 in a blend of short and long exposures to bring out the faint Earthshine on the dark side of the Moon and deep blue twilight sky while retaining details in the bright sunlit crescent. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a blend of 7 exposures from 1/30 second to 2 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop.

Unlike the single image, the lead image, repeated just above, is a multi-exposure blend (using luminosity masks), to bring out the faint Earthshine and deep blue sky, while retaining details in the bright crescent.

Once the sky gets dark enough to see Earthshine well, no single exposure can record the full range in brightness on both the day and night sides of the Moon.

Waxing Moon, Mars and the Taurus Clusters — The 4-day-old waxing crescent Moon on April 8, 2019 with it below Mars (at top) and the star clusters, the Hyades (at left, with reddish Aldebaran) and Pleiades (at right) in Taurus, and set into the deep blue evening twilight. This is with the 135mm Canon telephoto at f/2.8 with the Canon 6D at ISO 400, in a blend of 7 exposures from 1/4 second to 8 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop, to prevent the Moon from being too overexposed while retaining the stars and blue sky. The camera was tracking the sky.

April 8 was a great night for lunar fans as the crescent Moon also appeared between the two bright star clusters in Taurus, the Hyades and Pleiades, and below reddish Mars.

It was a fine gathering of celestial sights, captured above with a telephoto lens.

April 8 Sky

This show the chart I used to plan the framing, created with StarryNight™ software and showing the field of the 135mm lens I used.

The chart also shows why spring is best for the waxing Moon. It is at this time of year that the ecliptic – the green line – swings highest into the evening sky, taking the Moon with it, placing it high in the west above obscuring haze.

That makes it easier to see and shoot the subtle Earthshine. And to see sharp details on the Moon.

$The 4-day-old waxing crescent Moon on April 8, 2019 exposed for just the bright sunlit crescent, revealing details along the terminator. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, for a single exposure of 1/60 second. This is not a stack or mosaic.$

The 4-day-old waxing crescent Moon on April 8, 2019 exposed for just the bright sunlit crescent, revealing details along the terminator. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, for a single exposure of 1/60 second. This is not a stack or mosaic.

After the sky got darker I shot the crescent Moon in a short exposure to capture just the bright crescent, included above in two versions – plain and with labels attached marking the major features visible on a 4-day Moon.

If you missed “Earthshine night” this month, mark May 7 and 8 on your calendar for next month’s opportunities.

Clear skies!

January 20, 2018

Urban Orion

Urban Nightscape – Orion over Calgary

On a very clear night, Orion shines over the skyline of Calgary.

As I live in the country, it’s not often I shoot the stars from urban sites, and certainly not from downtown Calgary. But the combination of a clear night and a speaking commitment in Calgary provided a chance to see what was possible under ideal conditions.

The lead image is real – I did not paste an image of the sky taken at some other time or place over the skyline image.

However, the sky image is a longer exposure (10 seconds) than the ground (3 seconds) in order to bring out the stars better, while keeping the city lights under control with no overexposure. So it is sort of a high dynamic range blend.

The other factor that helped reveal stars as faint as shown here (fainter than what the naked eye can see) is the use of a light pollution reduction filter (a NISI Natural Night filter) to penetrate the yellow sky glow and provide a more pleasing colour to the sky.

Earlier in the night, during twilight when urban light pollution is not so much of an issue, I shot the waxing crescent Moon setting over the skyline.

Crresent Moon over Calgary

This is a panorama image made from high dynamic range blends of various exposures, to again accommodate the large range in brightness in the scene. But I did not use the NISI filter here.

These images demonstrate how you can get fine astronomy images even from urban sites, with planning and timing.

To that end, I used my favourite app, The Photographer’s Ephemeris, to determine where the sky elements would be as seen from a couple of viewpoints over the city that I’ve used in the past.

The blue spheres in the left image of TPE in its Night mode represent the Milky Way. That chart also shows the direction toward Orion over the city core.

The right image of TPE in its Day mode shows the position of the Moon at 6 pm that evening, again showing it to the left of the urban core.

Other apps are capable of providing the same information, but I like TPE for its ease of use.

Clear skies!

July 27, 2017July 27, 2017

The Night-Shadowed Prairie

The Night Shadowed Prairie

“No ocean of water in the world can vie with its gorgeous sunsets; no solitude can equal the loneliness of a night-shadowed prairie.” – William Butler, 1873

In the 1870s, just before the coming of the railway and European settlement, English adventurer William Butler trekked the Canadian prairies, knowing what he called “The Great Lone Land” was soon to disappear as a remote and unsettled territory.

The quote from his book is on a plaque at the site where I took the lead image, Sunset Point at Writing-on-Stone Provincial Park.

The night was near perfect, with the Milky Way standing out down to the southern horizon and the Sweetgrass Hills of Montana. Below, the Milk River winds through the sandstone rock formations sacred to the Blackfoot First Nations.

The next night (last night, July 26, as I write this) I was at another unique site in southern Alberta, Red Rock Coulee Natural Area. The sky presented one of Butler’s unmatched prairie sunsets.

This is “big sky” country, and this week is putting on a great show with a succession of clear and mild nights under a heat wave.

The waxing crescent Moon adds to the western sky and the sunsets. But it sets early enough to leave the sky dark for the Milky Way to shine to the south.

This was the Milky Way on Wednesday night, July 27, over Red Rock Coulee. Sagittarius and the centre of the Galaxy lie above the horizon. At right, Saturn shines amid the dark lanes of the Dark Horse in the Milky Way.

I’m just halfway through my week-long photo tour of several favourite sites in this Great Lone Land. Next, is Cypress Hills and the Reesor Ranch.

April 8, 2017April 8, 2017

The Austral Moon of Evening

Waxing Moon in Evening Twilight Colours

From the southern hemisphere the Moon appears “upside-down” and higher each night in the northern sky as it waxes from crescent to Full.

These are scenes from the last week as the Moon rose higher into the evening sky as seen from Australia.

A northerner familiar with the sky would look at these and think these are images of the waning Moon at dawn in the eastern sky.

Waxing Crescent Moon at Cape Conran — The “upside-down” waxing crescent Moon in the evening sky from Victoria, Australia, at Cape Conran, West Cape area, on the Gippsland Coast, at latitude 37° South. Earthshine lights the dark side of the Moon. This was March 31, 2017. The Moon lights a glitter path on the water. This is a single 1.3-second exposure at f/2 with the 85mm Rokinon lens, and Canon 5D MkII at ISO 400.

But no, these are of the waxing Moon (the phases from New to Full) with the Moon in the evening sky.

From the southern hemisphere the ecliptic – the path of the planets – and the path of the Moon arcs across the northern sky. So as the Moon waxes from New to Full phase it appears to the right of the Sun, which still sets in the west. The world still spins the same way down under!

So the Moon appears upside down and with the crescent phase the “wrong” way for us northerners.

Panorama of the Waxing Moon at Sunset at Welshpool Harbour — A 240° panorama from 16 segments.

This panorama taken April 4 sweeps from northwest to southeast, but looks north at centre, to capture the scene at sunset of the waxing 8-day gibbous Moon in the northern sky as seen from the southern hemisphere.

The angle between the Sun and Moon is just over 90°, shown here by the angle between the right-angle arms of the wharf, pointed to the west at left, to the north at centre, and to the east at right.

The Sun has set just north of west, while the Moon sits 13° east of due north. The Earth’s shadow rises as the blue arc at far right to the east opposite the Sun.

Philip Island Sunset and Waxing Moon Panorama — A 240° panorama from 15 segments.

The next night, April 5, I shot this panorama from Philip Island south of Melbourne. Again, it shows the waxing gibbous Moon in the north far to the right of the setting Sun in the west (at left).

Getting used to the motion of the Sun and Moon across the northern sky, and the Moon appearing on the other side of the Sun than we are used to, is one of the challenges of getting to know the southern sky.

Things just don’t appear where nor move as you expect them to. But that’s one of the great delights of southern star gazing.

July 1, 2015

Waterton Lakes in the Twilight

Happy Canada Day! From one of the most scenic places in the country.

I spent a wonderful four days and nights last week at Waterton Lakes National Park, Alberta, with near perfect weather conditions.

For one, the infamous winds of Waterton weren’t blowing, allowing me to shoot the iconic Prince of Wales Hotel reflected in the calm waters of Middle Waterton Lake at Driftwood Beach, with the waxing Moon above in the twilight sky.

Earlier in the evening, I was at the Maskinonge Overlook shooting some video for upcoming tutorials. At sunset I shot this image, below, of the Moon above the alpenglow of the last rays of sunlight.

The rising waxing gibbous Moon in the sunset sky over Maskinonge Wetlands at Waterton Lakes National Park, Alberta, June 2015. The last rays of sunset are illuminating the peaks in alpen glow. This is an HDR stack of 3 exposures with the Canon 60Da and 16-35mm lens.

Happy Canada Day!

And don’t forget to look west for the ongoing Venus-Jupiter conjunction. I missed the best night last night, June 30 – clouds! But here’s hoping for tonight.

June 22, 2015June 22, 2015

Reflections of Solstice Planets and Northern Lights

The summer solstice sky was filled with twilight glows, planets, and dancing Northern Lights.

What a magical night this was. The evening started with the beautiful sight of the waxing crescent Moon lined up to the left of the star Regulus, and the planets Jupiter and Venus (the brightest of the trio), all set in the late evening twilight.

They are all reflected in the calm waters of a prairie lake.

I shot the above photo about 11 p.m., as late a twilight as we’ll get. From here on, after solstice, the Sun sets sooner and the sky darkens earlier.

Later, about 12:30 a.m., as predicted by aurora apps and alert services, a display of Northern Lights appeared on cue to the north. It was never very bright to the eye, but the camera nicely picks up the wonderful colours of a solstice aurora.

At this time of year the tall curtains reaching up into space catch the sunlight, with blue tints adding to the usual reds fringing the curtain tops, creating subtle shades of magenta and purple.

The display made for a photogenic subject reflected in the lake waters.

June 20, 2015

A Twilight Triangle of Worlds

The three brightest objects in the night sky gathered into a tidy triangle in the twilight.

On Friday night, June 19, I chased around my area of southern Alberta, seeking clear skies to capture the grouping of the waxing crescent Moon with Venus and Jupiter.

My first choice was the Crawling Valley reservoir and lake, to capture the scene over the water. I got there in time to get into position on the east side of the lake, and grab some shots.

This was the result, but note the clouds! They were moving in quickly and soon formed a dramatic storm front. By the time I got back to the car and changed lenses, I was just able to grab the panorama below before the clouds engulfed the sky, and the winds were telling me to leave!

I drove west toward home, taking a new highway and route back, and finding myself back into clear skies, as the storm headed east. I stopped by the only interesting foreground element I could find to make a composition, the fence, and grabbed the lead photo.

Both it, and the second image, are “HDR” stacks of five exposures, to preserve detail in the dark foreground and bright sky.

It was a productive evening under the big sky of the prairies.

June 15, 2015

Heads Up! – June Moon Passes the Planets

This weekend watch for the waxing crescent Moon passing the “evening stars” of Venus and Jupiter.

On Friday, June 19 look west to see the crescent Moon a binocular field below bright Venus in the evening twilight.

The next night, Saturday, June 20, the Moon appears a little higher and below Jupiter.

On Sunday, June 21, the day of the summer solstice, look for the crescent Moon to the left of the star Regulus in Leo.

Venus and Jupiter are getting closer to each other each night, as they edge toward a very close conjunction on June 30 when they will appear just over a Moon diameter apart in the evening sky.

However, this weekend may bring better photogenic opportunities, with the picturesque crescent Moon near the two brightest planets in the sky.

May 22, 2015May 22, 2015

Urban and Rural Moons

The waxing Moon and Venus shine over contrasting landscapes, both urban and rural.

I shot the main image at top last night, May 21, from a site overlooking the urban skyline of Calgary, Alberta. The waxing Moon shines near Venus in the twilight sky.

By contrast I shot the image below the night before, from a location that couldn’t be more different – remote, rural Saskatchewan, on a heritage farmstead first settled in the 1920s by the Butala family. It is now the Old Man on His Back Prairie and Heritage Conservation Area.

Here, the crescent Moon shines a little lower, below Venus, amid the subtle colours of twilight in a crystal clear prairie sky.

However, as the top image demonstrates, you don’t need to travel to remote rural locations to see and photograph beautiful sky sights. Twilight conjunctions of the Moon and bright planets lend themselves to urban nightscapes.

April 26, 2015

Amazing Scenery on the Eight-Day Moon

Incredible detail stands out along the terminator of the eight-day Moon.

This was the Moon on the evening of April 26, with the waxing Moon eight days past New and one day past First Quarter Moon. It’s a great phase to explore the surface of the Moon.

In the north the arcs of the Alps and Apennine mountain ranges encircle Mare Imbrium.

In the south, craters pepper the Highlands in stark relief. Tonight, the Straight Wall was just beginning to catch the light of the rising Sun, creating a very sharp, straight shadow.

The regions along the terminator – the boundary between light and dark – at left are seeing the first sunlight in two weeks. To the right, on the more brightly lit portion of the near side of the Moon, the dark mare areas stand out in various shades of grey. Systems of rays splash out from bright, geologically fresh crater impacts.

On the technical side, this is a mosaic of two overlapping images, one for the northern and one for the southern hemisphere, taken through a Celestron C9.25 telescope at a focal length of 2300mm. I stitched them with Adobe Camera Raw’s new (as of last week’s update) ability to stitch images into a Raw-format panorama file.

April 21, 2015April 21, 2015

Conjunction Over the Old Barn

The Moon and Venus shine in conjunction over an old pioneer barn.

Tonight, April 21, the waxing crescent Moon passed a wide eight degrees to the left of Venus. That’s a wide conjunction to be sure, if we can even call it a conjunction!

Nevertheless, when the two brightest objects in the night sky come together it’s worth looking at and photographing.

I had planned to drive west, to the Kananaskis area of southern Alberta, to shoot the celestial scene over the Rockies. But clouds to the west thwarted those plans.

As it is, I still fought the oncoming clouds out on the plains. I chose a favourite old barn near home. It made a rustic foreground to the twilight sky.

Venus remains a brilliant “evening star” all spring and into the early summer. We’ll see a similar wide passage of the crescent Moon by Venus a month from now, on the evening of May 21.

April 17, 2015April 17, 2015

Heads Up! – Dual Conjunctions in the Spring Sky

On the evening of April 21 the waxing Moon shines near Venus, while Mercury appears near Mars.

Say goodbye to the winter sky, as Orion and Taurus sink into the western twilight. Joining them is an array of planets, and the Moon.

Look west on April 21 and you’ll see the waxing crescent Moon near brilliant Venus, with both above the Hyades star cluster and the bright star Aldebaran in Taurus.

The thinner Moon will appear below Venus the night before, on April 21, while on April 22, the waxing Moon, then a wider crescent, will sit well above Venus.

If you have an unobstructed view to the west also look for the pairing of Mercury and Mars low in the twilight. You might need to use binoculars to pick them out.

Mercury is just beginning its best evening appearance of the year for the northern hemisphere. So if you miss it April 21, you have another couple of weeks to find it in the evening sky.

Waxing Moon Amid the Hyades (Telescope)

On the nights around April 21, also look for Earthshine lighting the dark side of the Moon. You can see the night side of the Moon because it is being illuminated by sunlight reflecting off the Earth, shining brightly in the lunar sky.

The above image is a view of Earthshine from a month ago, on March 24, when the Moon appeared in the Hyades star cluster.

Enjoy the spring sky adorned by Venus as a bright “evening star,” and joined by the Moon on April 21.

March 24, 2015March 24, 2015

Moon Amid the Hyades

The waxing crescent Moon shines amid the stars of the Hyades cluster.

I shot these on the evening of March 24 when, from western North America, the Moon appeared superimposed in front of the sprawling Hyades star cluster in Taurus.

The main image at top is with a 200mm telephoto lens and takes in most of the Hyades and the bright red star Aldebaran at lower left. Unfortunately, it also includes a blue lens flare from the brilliant and overexposed crescent, a tough element to “photoshop” out.

The image is a high dynamic range stack of 3 exposures. Even so, I purposely overexposed the Moon to bring out the stars and their colours.

This close up of the Moon includes fewer Hyades stars, but with the Moon centred I was able to avoid the lens flare. It’s an HDR stack of 5 exposures, to capture details in the sunlit crescent as well as on the dark side of the Moon lit by blue Earthshine.

These are the last telescopic shots from my winter in New Mexico, as the telescope and mount gets packed up tomorrow, in preparation for the trip back to Canada.

It’s been a fabulous winter of sky shooting, with some 500 gigabytes of images shot, processed, and archived!

March 22, 2015March 22, 2015

Moon and Venus at the Place of the Mountain Gods

The Moon meets Venus over a New Mexico pond in the heart of the Apache homelands.

This was the scene on Sunday evening, March 22, 2015, as the waxing crescent Moon appeared near Venus in one of the best conjunctions of the spring.

Earthshine lights the dark side of the Moon, while Mars also appears, below the Moon-Venus pair.

For these images I set up on the picturesque grounds of a resort called the Inn of the Mountain Gods, near Ruidoso, New Mexico, a ski resort in winter and a cool mountain retreat in summer.

The resort, run by and on land owned by the Mescalero Apache, honours the spirits of the four sacred mountains on Apache land: Sierra Blanca, Guadalupe Mountains, Three Sisters Mountain and Oscura Mountain Peak.

As the resort brochure states, “These four mountains represent the direction of everyday life for our Apache people. Our grandparents would often speak of the place called White Mountain. It was there that the creator gave us life and it is a special place.”

I shot this image a little later in the evening when the sky was darker, stars were beginning to appear, and thin clouds added haloes around the waxing Moon and Venus. I think the clouds added a photogenic touch.

February 16, 2015February 16, 2015

Heads Up! – The Moon Meets Mars & Venus

This Friday, February 20, look west to see one of the best planet conjunctions of 2015.

On the evening of February 20, the waxing crescent Moon joins Venus and Mars in the western sky to create a tight gathering of worlds in the twilight.

The trio of worlds will be just one degree apart, close enough to fit within the low-power field of a telescope.

However, the conjunction will be easy to sight with the unaided eye, with the possible exception of Mars itself. It is now dim enough, and so close to brilliant Venus and the Moon, that picking it out might be tough without optical aid.

But any binoculars will nicely show this wonderful trio, as here:

This closeup image shows the field through binoculars, which typically frame about six to seven degrees of sky. The Moon, Venus and Mars will be a mere one degree apart.

The next night, February 21, the crescent Moon will sit above the Venus-Mars pair. But the two planets will be even closer together, just 1/2 degree apart. They will be a little farther apart on February 22.

Venus and Mars pass in conjunction this weekend as Mars sinks lower into the sky, to disappear behind the Sun by spring, while Venus climbs higher, to dominate the spring sky this year.

This will be a photogenic conjunction, so get your camera out. Use a normal to moderate telephoto lens (50mm to 135mm) to frame the celestial gathering above a scenic horizon.

January 21, 2015

Moon, Mercury and Venus in Conjunction

This was the scene on Wednesday night, as the waxing Moon formed a triangle with Mercury and Venus.

Skies cleared nicely this evening, providing a beautiful view and photogenic scene of the inner planets near the waxing Moon.

On January 21 the crescent Moon appeared with Venus (at left) and Mercury (below), and with the trio above the lights of Silver City, New Mexico.

Compare this view of reality with the graphic from my blog of a few days ago, and with a similar scene a month earlier with the Moon closer to Venus but with no Mercury.

With the Moon now returning to the sky, sighting Comet Lovejoy will become more difficult.

On Thursday night, January 22, the Moon will be higher and shine near Mars.

Happy viewing!

January 19, 2015

Heads Up! Sight the Thin Moon by Mercury & Venus

On Wednesday, January 21 look low in the southwest for a conjunction of the Moon and inner planets.

Mercury is ending its brief evening appearance and proximity to Venus. But this week you can still spot it a binocular field or so below Venus as it descends back toward the Sun.

On Wednesday, January 21, look low in the southwest to sight the thin waxing crescent Moon sitting near Venus and Mercury, forming a wide triangle of inner rocky worlds.

The other rocky planet in the inner solar system, Mars, shines higher up in the evening twilight as a moderate brightness reddish star. The next night, January 22, the waxing Moon will sit beside Mars in a wide conjunction.

Catch the Moon-Mercury-Venus trio early, as they will set an hour or so after local sunset.

Clear skies!

December 26, 2014December 26, 2014

Both Sides of the Boxing Day Moon

The dark and bright side of the Moon appear together in a portrait of the 5-day Moon.

This was the waxing crescent Moon on Friday, December 26 – Boxing Day.

In this image you can see both the bright crescent directly lit by the Sun, and details in the dark side of the Moon lit only by sunlight reflected off Earth – Earthshine.

I used a composite of 5 exposures from 8 seconds to 1/50 second to capture both sides of the Moon, with the images merged in Photoshop’s HDRPro module.

I shot the images through my TMB 92mm apo refractor using the Canon 60Da camera, on a very clear night in New Mexico.

Happy Boxing Day to all!

December 24, 2014December 24, 2014

The Christmas Eve Sky

This was the sky on the night before Christmas, with the Moon setting and Orion rising.

It was a crisp and calm night on Christmas Eve, with the waxing Moon shining beside Mars in the west at right. The western sky was marked by the faint tower of light called the Zodiacal Lights. To the east at left, Orion was rising beside the Milky Way.

The main image is a 180° panorama taken at the City of Rocks State Park, south of Silver City, New Mexico, and a particularly photogenic site for nightscape images.

This was the scene earlier in the evening with the Moon beside Mars, and the pair well above Venus down in the twilight, all framed by one of the park’s windmills.

Here is a close-up of Orion climbing over the rock formations in the state park. This is a single exposure with the foreground lit by the waxing crescent Moon.

Merry Christmas to all and to all a good night.

December 22, 2014December 22, 2014

Venus and a Silvery Moon over Silver City

The thin Moon and Venus hang over the lights of Silver City, New Mexico.

Tonight, December 22, the 24-hour-old crescent Moon shone a binocular field to the right of brilliant Venus. I caught both hanging in the sky over downtown Silver City, set in stunningly clear twilight.

Venus is just beginning what promises to be a spectacular evening appearance in the western sky over the next few months, as it climbs higher.

The Moon, on its shorter cycle around the sky, is emerging into the evening sky for the end-of-year holidays. Watch it wax into a quarter Moon, then to Full, over the next two weeks. Tonight, the glow of Earthshine was prominent lighting the dark side of the Moon.

I shot this from east of the city, using a 135mm telephoto on my Canon 60Da camera.

Happy holidays to all!

December 4, 2014

Ring Around the Moon

Ice crystals create a ring of light around the waxing Moon.

Clouds have moved in this week in New Mexico but the advancing weather system also brought an atmosphere filled with high altitude ice crystals.

Earlier this week they created a lunar halo – a ring around the Moon. If you look closely you’ll see there are two rings. On the left and right sides (east and west) the halo splits into two. This is an effect of two haloes superimposed: the classic 22° halo and what’s called the “circumscribed halo” which changes shape and size depending on the altitude of the Sun or Moon.

In this case, the Moon was 62° up, and the appearance of the circumscribed halo exactly matches what computer simulations predict for this altitude.

See Les Cowley’s wonderful website on Atmospheric Optics and the page on the shape of the circumscribed halo.

The long 30-second exposure brought out the stars in the moonlit sky.

They say such haloes presage poor weather. This week that proved true as clouds and rain moved in.

November 25, 2014November 25, 2014

The Dark Side of the Moon in Twilight

The waxing crescent Moon shines amid the stars and deep blue twilight.

This was the scene last night, as the two-day-old Moon reappeared in the evening sky as a thin crescent.

The Moon looks full because most of the side facing us was brilliantly lit by Earthshine, sunlight reflected off the Earth and lighting the Moon. Here, only the thin crescent at right is directly lit by the Sun.

This was a particularly bright example of Earthshine, likely because so much of the northern part of the Earth is now covered with cloud and snow, making Earth even more reflective than it usually is.

To capture this scene through a telescope, I shot a set of high-dynamic-range exposures, from long to short, to capture the huge range in brightness from the dayside to the darkside of the Moon. The long exposure also captured the stars in the deep blue twilight of a clear New Mexico sky.

October 30, 2014October 30, 2014

Open Road, Open Sky

A desert highway leads off into an open blue sky with the waxing Moon.

This week I’m on the road heading south for the winter. Today, I was on US 89, one of the most spectacular roads on the continent, passing through southern Utah and northern Arizona.

At left are the Vermilion Cliffs in Arizona, contrasting with the blue sky and the quarter Moon rising in the east at right.

I took this view minutes earlier, from a viewpoint above the desert as US 89 descends from the Kaibab Plateau and the area around the North Rim of the Grand Canyon.

I have not driven through this area of the U.S. Southwest in 20 years. I’ll be back through here in spring, when I hope to shoot the April 4 total lunar eclipse from the Four Corners area.

September 28, 2014

Moon and Twilight Planets over the Bow River

The waxing Moon shines between Saturn and Mars over the waters of the Bow River.

It was a beautiful autumn evening for watching the twilight showing of the crescent Moon accompanied by Saturn (at right of centre) and the pairing of Mars (at left, above) with his rival red star, Antares in Scorpius (at left, below).

The river is the Bow, with its headwaters at Bow Glacier in Banff.

To shoot this scene I drove to the grounds of the Blackfoot Crossing Historical Park south of Cluny, Alberta to take advantage of its viewpoint overlooking the Bow River and the heart of the traditional Siksika First Nations tribal lands.

It was here, in the valley below, that Treaty Seven was signed between Chief Crowfoot and Colonel James Macleod in September 1877. Today, a beautiful interpretive centre sits on the hillside at the heart of Blackfoot country.

September 8, 2014September 9, 2014

Stars on Ice – The Columbia Icefields by Moonlight

The stars trail over the glaciers of the Columbia Icefields.

What an amazing night this was! You rarely get pristine cloudless skies over the Icefields. Some cloud is almost always blowing off the ice. But last Saturday in Jasper National Park was as clear as it gets.

The Moon was bright, as a waxing gibbous just off frame at left. It lit the landscape like it was day.

I shot with two cameras, one doing a time-lapse motion control sequence panning across the scene. The other was a fixed camera shooting 20-second exposures at 1-second intervals. The resulting frames from the fixed camera, 270 in this case, are multi-purpose:

– I stacked about 100 of them to make the star trail composite above. Two frames supplied the stars at the beginning and end of the trails. Another single frame supplied the ground, to avoid the shadows being blurred by the Moon’s motion if you used the ground composited from all 100 frames.

– I can also take the full set of 270 frames and sequence them into a time-lapse movie of the stars moving over the landscape.

Before beginning the time-lapse sequences I shot this 180° panorama, made of 5 segments stitched in PTGui software. It extends from the southwest at left, where the Milky Way is barely visible, to the north at right, with the Big Dipper over the Icefields Parkway.

Click on it for a bigger view.

This is the camera setup, with the camera on the right taking the star trail image I feature at top.

The Athabasca Glacier is at left, the Stutfield Glacier at right.

Midnight under moonlight is when to see the Icefields! This is the lower parking lot, at the start of the trail up to Athabasca Glacier. This is packed with cars, RVs and buses by day, but at night I was the only one there.

September 5, 2014

Pyramid Island Sky Panorama

The sky presents a panoramic show from Pyramid Island in Jasper National Park.

What a wonderful place to watch the stars. Last night I walked out to Pyramid Island in Jasper, via the historic boardwalk built in the 1930s. The site provides a panorama view around the lake and sky.

To the left is the “mainland.” Just left of centre the waxing gibbous Moon is setting over Pyramid Lake.

To the right of centre, the boardwalk leads out the small island, with Pyramid Mountain behind it.

To the right of the frame, a faint aurora glows to the northeast over the still waters of the lake.

This is a 360° panorama shot with the 15mm full-frame fish-eye lens in portrait orientation, with the segments stitched with PTGui software.

After shooting some panoramas I walked to the end of the island and shot this view looking north and northwest to Pyramid Mountain. The Big Dipper is to the right of the peak, and the aurora lights up the northern horizon at right.

As I shot these images, the night was absolutely quiet. Until the wolves began to howl at the north end of the lake, in mournful howls that echoed across the waters.

It was one of the most spine-chilling moments I’ve experienced in many years of shooting landscapes at night.

August 6, 2014August 6, 2014

Prairie Sunset Panorama

What a spectacular sunset tonight. The Sun is just going down in a blaze of red, while the waxing Moon shines in the deep blue twilight.

I grabbed the camera fast when I saw this happening out my front window, and raced out to the ripening wheat field across the road.

The top image is a 360° panorama of the sky, with the Sun at right and the Moon left of centre. The zenith is along the top of the image.

I used a 14mm lens in portrait mode to cover the scene from below the horizon to the zenith, taking 7 segments to sweep around the scene.

You can see the darkening of the sky at centre, 90° away from the Sun, due to natural polarization of the skylight.

I shot this sunset image a little earlier, when the Sun was higher but still deep red in the smoky haze that has marked the sky of late. It certainly gives the scene a divine appearance!

This is a 5-exposure high-dynamic-range composite to capture the tonal range from bright sky to darker ground, the wheat field. I increased the contrast to bring out the cloud shadows – crepuscular rays.

I boosted colour vibrancy but didn’t alter the actual colours – it was a superb sky.

I used PTGui v10 to stitch the panorama at top and Photomatix Pro to stack and tone the HDR set. While Photoshop is wonderful it did not work for assembling either of these images.

May 31, 2014

The Thin Moon of May

May ends with a thin waxing Moon returning to the evening sky.

This was the scene on a fine Friday evening, May 30, as the two-day-old Moon returned to the western sky.

Mercury was not far away, and is in this frame but at far upper right. I wasn’t really framing the shot with Mercury in mind, but the Moon and clouds.

This frame is one of 440 I shot for a time-lapse sequence of the setting Moon and moving clouds. This is the result, nicely deflickered with LRTimelapse software, an essential tool for time-lapse processing.

How many times have I tried to shoot the Moon or Mercury low in the west and been foiled by cloud near the horizon? Notice the rain falling from the western cloud. Some place near Calgary was getting wet!

April 30, 2014

New Mexico New Moon

The thin waxing crescent Moon returned to the evening sky tonight, seen here in the deepening blue of a New Mexico evening.

I’m in Silver City, New Mexico (altitude 5900 feet) for a few days and nights, checking out places to spend next winter, under clearer and warmer skies than back home … and with rarely any snow to shovel.

This was the scene tonight, on the ranch road with one of the prime property choices – astronomers check real estate locations by day and night!

The crescent Moon is lit by Earthshine as it sits amid the deep blue twilight. The stars of Taurus show up flanking the Moon, with the Hyades at left and Pleiades at right.

This image is a high-dynamic range stack of 6 exposures from 2 to 20 seconds, to capture the ground detail without blowing out the Moon. Lights from an approaching pickup truck nicely lit the trees during the final longest exposure.

For the technically minded, I stacked the images using Photoshop CC HDR Pro, then “tone-mapped” them using Adobe Camera Raw in 32 bit mode.

The sky was hazy all day and evening, from wind-blown dust common to the area. Fierce southerly winds were whipping up dust all day, which hung in the sky all evening as well.

The sunset was a golden yellow from all the dust in the air. Once it got dark the sky lacked the ideal desert transparency, muting the zodiacal light I saw last night from the Chiricahuas.

Not every night is perfect in the high desert!

April 6, 2014

The Waxing Moon of Oz

The waxing Moon shines amid twilight clouds from Australia.

While it looks like a waning morning Moon, this is the waxing evening Moon, inverted compared to northern hemisphere views. I shot this two evenings ago as the crescent Moon enters the evening sky.

With the return of the Moon to the sky, my dark sky observing sessions end. Next on the agenda is the total eclipse of the Full Moon on April 15. I hope to shoot that over the ocean from the Australian coast.

December 15, 2013

Moon over the Chiricahuas

The waxing gibbous Moon rises over the Chiricahua Mountains of southeast Arizona.

This was the stunning scene on Sunday night, December 15, as I drove out to Chiricahua National Monument south of Willcox, Arizona for some moonlight photography. I stopped on Highway 186 to catch the colourful twilight in the east with the Moon rising over the desert mountains.

This image, taken a few minutes later, shows a darker sky but with more prominent crepuscular rays – shadows cast by distant clouds to the west where the Sun set. A photogenically placed windmill adds to the scene.

I love the contrast of Earth tones and twilight tints – a very desert-like palette.

December 5, 2013December 8, 2013

Adobe Moon and Venus

The waxing crescent Moon shines above Venus and our adobe house in New Mexico.

Tonight, December 5, the clouds cleared in time for us to catch a glimpse of the crescent Moon above Venus, now at its most brilliant for the year.

They shine above the main house at the Painted Pony Resort where I am this week for a stint of astrophotography with a dozen other Canadians escaping winter up north. But it’s cold here, too – it might go down to freezing tonight. Horrors!

For this shot I made liberal use of shadow and highlight recovery at the Adobe Camera Raw stage and in Photoshop to recover as much detail as I could in the overexposed Moon at top. However, the long exposure nicely brings out the stars in the moonlit sky. I also like the contrast of pastel colours.

August 19, 2013

Dinosaur Moon

The waxing Moon rises into a colourful twilight sky over the badlands of Dinosaur Provincial Park.

What a great night it was last night! Warm summer temperatures (at last!) allowed for shirtsleeve shooting even well after dark. To shoot on the warm August night I went out to Dinosaur Provincial Park, a magical place to be at sunset and in the summer twilight. The colours on the badlands are wonderful. It’s earth-tones galore, with the banded formations from the late Cretaceous blending with the sagebrush and prairie flowers.

This was the scene after sunset, as the waxing Moon rose into the eastern sky coloured by the blue band of Earth’s shadow, the pink Belt of Venus and dark blue streaks of cloud shadows converging to the point opposite the Sun. That’s where the Moon will be Tuesday night when it’s full. But last night it was a little west of the anti-solar point.

I managed to grab this image as soon as I got to my photo spot on the Badlands Trail, just in time to catch the last rays of the setting Sun illuminating the bentonite hills of the Badlands. Both shots are frames from a 450-frame time-lapse, taken with a device that also slowly panned the camera across the scene over the 90-minute shoot.

It, and three other time-lapses I shot after dark, filled up 40 gigabytes of memory cards. It’s been a terabyte summer for sure!

July 12, 2013

Sunset Panorama at Reesor Ranch

The setting Sun lights up a classic Canadian prairie skyscape.

This was sunset last night, July 11, from the historic Reesor Ranch in southwest Saskatchewan, on the north edge of the Cypress Hills. The clouds opened up across the sky in a Chinook arch, with clearing to the west where the waxing Moon and Venus were also setting into the twilight.

It was a stunning scene looking out over the plains from the highlands of the hills.

I’m in the area for a week of shooting, weather permitting.

This shot is a 7-section panorama, stitched with Photoshop’s Photomerge command.

March 12, 2013

Comet PANSTARRS Spectacle — With the Waxing Moon

This was the night for Comet PANSTARRS! How often do we get to see a view like this, with a comet sitting beside a thin crescent Moon. Spectacular!

Again tonight, about a dozen visiting and resident Canadians gathered for a roadside star party north of Rodeo, New Mexico, to view the comet and Moon setting together over the Chiricahua Mountains. It was a stunning sight and made for a picture postcard image. The two set almost simultaneously, with the tail of the comet and “dark side of the Moon” lit by Earthshine the last to disappear behind notches in the mountain ridge.

And tonight, with the comet higher, it was visible to the naked eye for the first time, but only just – the sighting was made easier because you knew exactly where to look.

The Moon was just 3o+ hours old, so appeared as a very thin crescent. The entire disk of the Moon was visible, the rest lit by Earthshine, sunlight reflected off the Earth. In the clear New Mexico air, the Earthshine was easy to see even in the bright twilight. But adding in the comet made for a once-a-lifetime view.

As soon as they set together, we all cheered and applauded, almost like at an eclipse. It was a memorable night, the kind you always hope for from a comet. PANSTARRS performed tonight!

December 19, 2012December 19, 2012

The Down Under Waxing Moon

To northern eyes this looks like an old Moon in the morning sky, but this is really a young Moon in the evening sky – seen from Australia.

This was the waxing crescent Moon a few nights ago in the early evening sky. Because I took this from a latitude of 30° south, the Moon is turned over almost 90° from the way northern hemisphere viewers would see it from Canada or the northern U.S.

For this image, I shot ten exposures from 1/30s to 15 seconds and merged them into one “high dynamic range” composite using Photomatix Pro software. The result is an image with detail in both the bright sunlit crescent and in the dark side of the Moon visible here lit by Earthshine, sunlight reflected off the Earth. The resulting “HDR image” compressed the wide range of brightness into one image, to show the Moon the way your eye would see it but that photo technology is still not capable of recording in one exposure.

September 23, 2012September 23, 2012

Right Angle Moon

Saturday night was a fine evening for witnessing the geometry of the night sky.

This is sunset on the evening of the autumnal equinox, September 22, 2012, with a first quarter Moon in the sky. The image illustrates the geometry of the quarter Moon’s position, which is always 90° away from the Sun, a quarter of the way around its orbit in its monthly cycle.

In this case, because the Sun (at right) was on the equinox position on the ecliptic, it was setting due west this night (something it does only on the dates of the fall or spring equinox). This put the quarter Moon (at left) 90° away, due south at sunset.

Draw a line from the Moon to your eye (the camera) and then back out to the Sun and it forms a 90° right angle. This geometry holds true for any quarter Moon, but being equinox the Sun and Moon were nicely aligned due west and south, making their right angle arrangement more obvious.

I took this shot from the grounds of the Rothney Astrophysical Observatory on the occasion of their monthly Open House.

September 5, 2011September 6, 2011

Moon over Saskatchewan River Crossing

This is how the night started, on Sunday evening, September 4 — as clear a night as you could ask for in the mountains. A quarter Moon hangs over the peaks of the Continental Divide, with alpen glow, the last rays of the Sun, illuminating the mountains around Saskatchewan River Crossing, in Banff.

The North Saskatchewan River flows east out of the mountains here, after being joined by the Mistaya and Howse rivers. It was here, in the early 1800s, that David Thompson and his party of fur traders from the North West Company entered the Rockies and heading up over Howse Pass off frame to the right, to trade with the Kootenays in the interior of what is now British Columbia.

This is David Thompson country, named for one of the world’s greatest geographers and mapmakers. He mapped most of western Canada and down into the Oregon Territory. All using compasses, sextants, a Dolland refractor telescope (to observe the moons of Jupiter for telling time), and his skills as an astronomer. The Kootenays called him Koo-Koo-Sint — the man who watches the stars.

It was also here, on these open river plains, that James Hector, mapping southern Alberta with the Palliser Expedition, observed Comet Donati in September 1858.

This is a place in the Rockies with many ties to history and to astronomy.

August 7, 2011August 7, 2011

Moon in the Mountains

I’ve been chasing the Moon this week. I caught up with it last Thursday night, August 4, in Banff, with the waxing crescent Moon low in the southwest at dusk.

The location is the upper Vermilion Lake just outside the Banff townsite. The golden reflection of the low Moon on the water, the slope of the mountainside and its reflection, the dock and steps, and the tail lights from a vehicle on Highway 1 just up the hill (I decided to leave them in!) make for what I think is an interesting composition of converging lines.

I got set up and in position just in time to catch the scene at the magic hour of twilight, when the sky is dark enough the show deep colours and the Moon’s entire disk shows up, but before the sky gets too dark and the Moon too bright to make an interesting scene.

Even so, the contrast in such a scene is still very high. So to capture it more as your eye would have seen it I used a stack of five exposures, taken in rapid succession, each 2/3rds of an f-stop apart. I then merged the frames with Photoshop’s High Dynamic Range routine to create a scene that brings out detail in the foreground without overexposing the Moon and sky.

A technical method to capture a simple scene of serenity in the mountains.
