The Waxing Moon of Spring




Four-Day-Old Moon with EarthshineSpring is the season for Earthshine on the waxing Moon.

April 8 was the perfect night for capturing the waxing crescent Moon illuminated both by the Sun and by the Earth.

The phase was a 4-day-old Moon, old enough to be high in the sky, but young enough – i.e. a thin enough crescent – that its bright side didn’t wash out the dark side!

In the lead photo at top, and even in the single-exposure image below taken earlier in a brighter sky, you can see the night side of the Moon faintly glowing a deep blue, and brighter than the background twilight sky.

Four-Day-Old Moon in Blue Twilight
The 4-day-old waxing crescent Moon on April 8, 2019 in a single exposure when the Moon was still in the bright blue twilight. Even so, the faint Earthshine is just becoming visible. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a single 1/8-second exposure.

This, too, is from sunlight, but light that has bounced off the Earth first to then light up the night side of the Moon.

If you were standing on the lunar surface on the night side, the Sun would be below the horizon but your sky would contain a brilliant blue and almost Full Earth lighting your night, much as the Moon lights our Earthly nights. However, Earth is some 80 times brighter in the Moon’s sky than even the Full Moon is in our sky.

Four-Day-Old Moon with Earthshine
The 4-day-old waxing crescent Moon on April 8, 2019 in a blend of short and long exposures to bring out the faint Earthshine on the dark side of the Moon and deep blue twilight sky while retaining details in the bright sunlit crescent. This is with the 105mm Traveler refractor and 2X AP Barlow lens for an effective focal length of 1200mm at f/12, and with the cropped-frame Canon 60Da at ISO 400, in a blend of 7 exposures from 1/30 second to 2 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop.



Unlike the single image, the lead image, repeated just above, is a multi-exposure blend (using luminosity masks), to bring out the faint Earthshine and deep blue sky, while retaining details in the bright crescent.

Once the sky gets dark enough to see Earthshine well, no single exposure can record the full range in brightness on both the day and night sides of the Moon.



Waxing Moon, Mars and the Taurus Clusters
The 4-day-old waxing crescent Moon on April 8, 2019 with it below Mars (at top) and the star clusters, the Hyades (at left, with reddish Aldebaran) and Pleiades (at right) in Taurus, and set into the deep blue evening twilight. This is with the 135mm Canon telephoto at f/2.8 with the Canon 6D at ISO 400, in a blend of 7 exposures from 1/4 second to 8 seconds, blended with luminosity masks from ADP Pro3 extension panel in Photoshop, to prevent the Moon from being too overexposed while retaining the stars and blue sky. The camera was tracking the sky.

April 8 was a great night for lunar fans as the crescent Moon also appeared between the two bright star clusters in Taurus, the Hyades and Pleiades, and below reddish Mars.

It was a fine gathering of celestial sights, captured above with a telephoto lens.

April 8 Sky

This show the chart I used to plan the framing, created with StarryNight™ software and showing the field of the 135mm lens I used.

The chart also shows why spring is best for the waxing Moon. It is at this time of year that the ecliptic – the green line – swings highest into the evening sky, taking the Moon with it, placing it high in the west above obscuring haze.

That makes it easier to see and shoot the subtle Earthshine. And to see sharp details on the Moon.

After the sky got darker I shot the crescent Moon in a short exposure to capture just the bright crescent, included above in two versions – plain and with labels attached marking the major features visible on a 4-day Moon.

If you missed “Earthshine night” this month, mark May 7 and 8 on your calendar for next month’s opportunities.

Clear skies!

— Alan, April 9, 2019 / © 2019 Alan Dyer / AmazingSky.com



Banff by Night


Milky Way Reflections at Bow Lake

Three perfect nights in July provided opportunities to capture the night sky at popular sites in Banff National Park.

When the weather forecast in mid-July looked so promising I made an impromptu trip to Banff to shoot nightscapes and time-lapses under unusually clear skies. Clouds are often the norm in the mountains or, increasingly these days, forest fire smoke in late summer.

But from July 15 to 17 the skies could not have been clearer, except for the clouds that rolled in late on my last night, when I was happy to pack up and get some sleep.

Conjunction over the Continental Divide with Train

My first priority was to shoot the marvellous close conjunction of the Moon and Venus on July 15. I did so from the Storm Mountain viewpoint on the Bow Valley Parkway, with a cooperative train also coming through the scene at the right time.

The Milky Way and Mars over Storm Mountain

This was the view later with the Milky Way and Mars over Bow Valley and Storm Mountain.

Bow Lake by Night Panorama

The next night, July 16, was one of the most perfect I had ever seen in the Rockies. Crystal clear skies, calm winds, and great lake reflections made for a picture-perfect night at Bow Lake on the Icefields Parkway. Above is a 360° panorama shot toward the end of the night when the galactic centre of the Milky Way was over Bow Glacier.

Streaks of green airglow arc across the south, while to the north the sky is purple from a faint display of aurora.

Earlier that night the usual auroral arc known as Steve put in an unexpected appearance. It was just a grey band to the eye, but the camera picked up Steve’s usual pink colours. Another photographer from the U.S. who showed up had no idea there was an aurora happening until I pointed it out.

Mars and the Milky Way at Herbert Lake

My last night was at Herbert Lake, a small pond great for capturing reflections of the mountains around Lake Louise, and the Milky Way. Here, brilliant Mars, so photogenic this summer, also reflects in the still waters.

At each site I shot time-lapses, and used those frames to have some fun with star trail stacking, showing the stars turning from east to west and reflected in the lake waters, and with a single still image taken at the end of the sequence layered in to show the untrailed sky and Milky Way.

But I also turned those frames into time-lapse movies, and incorporated them into a new music video, along with some favourite older clips reprocessed for this new video.

Banff by Night (4K) from Alan Dyer on Vimeo.

Enjoy! And do enlarge to full screen. The video is also in 4K resolution.

Clear skies!

— Alan, August 2, 2018 / © 2018 Alan Dyer / AmazingSky.com



Dawn Sky Delights


Aldebaran About to be Occulted by the Moon

It was one of those mornings when the sky was full of wonder.

After days and nights of smoke from unfortunate fires burning not far away, including in my favourite national park of Waterton Lakes, the sky cleared enough this morning, September 12, to reveal some fine sights.

At 6 a.m. the waning gibbous Moon passed in front of the star Aldebaran in Taurus. It is performing many such occultations of Aldebaran this year, but most aren’t well seen from any one location. This one was ideal, right from my backyard.

The lead image is a “high dynamic range” stack of several exposures showing the waning Moon and star set in some high haze adding the sky colours.

The star winked out behind the Moon’s bright limb as the Moon advanced from right to left (west to east) against the background sky.

Occultation of Aldebaran
Aldebaran nearing the limb of the Moon.
This shows a composite sequence, with images of the star taken every four minutes blended with a single image of the Moon. While it looks like the star is moving, it is really the Moon that is edging closer to Aldebaran.

The star reappeared from behind the dark limb of the Moon, but five minutes after sunrise, with the Moon in a bright blue sky. Still, the star stood out nicely in binoculars and in the telescope for this view.

Aldebaran Near the Moon in Day Sky
Aldebaran off the dark limb of the Moon.
Aldebaran is the point of light at right, just off the invisible edge of the Moon.

I shot stills and video, and compiled them into this short video.

Enlarge it to full screen to view it properly.

Meanwhile, over to the east the twilight sky was awash in planets.

Rocky Planets at Dawn with Labels (Sept. 12, 2017)
The line of dawn planets, with labels.
All the three inner terrestrial worlds were there: Venus, at top, Mercury below Regulus, and Mars lowest of the trio. Of course, a fourth terrestrial world is in the photo, too – Earth!

Mercury was at its greatest western elongation this morning, placing it as far from the Sun and as high in the sky as it gets, with this autumn appearance the best of 2017 for a morning showing for Mercury. Even so, you can see how Mercury is always low and easy to miss. However, this morning it was obvious to the naked eye.

Mars and Mercury will be in close conjunction at dawn on the morning of September 16.

Rocky Planets at Dawn (Sept. 12, 2017)

It was a fine morning to be up early and enjoy the solar system show.

— Alan, September 12, 2017 / © 2017 Alan Dyer / amazingsky.com



Totality over the Tetons — the Music Video


Totality over Tetons Title Image

I present the final cut of my eclipse music video, from the Teton Valley, Idaho.

I’ve edited my images and videos into a music video that I hope captures some of the awe and excitement of standing in the shadow of the Moon and gazing skyward at a total eclipse.

Totality over the Tetons from Alan Dyer on Vimeo.

The video can be viewed in up to 4K resolution. Music is by the Hollywood session group and movie soundtrack masters, Audiomachine. It is used under license.

Eclipse Triumph Selfie (Wide)
Me at the 2017 total solar eclipse celebrating post-eclipse with four of the camera systems I used, for close-up stills through a telescope, for 4K video through a telephoto lens, and two wide-angle time-lapse DSLRs. A fifth camera used to take this image shot an HD video selfie.
Never before have I been able to shoot a total eclipse with so many cameras to capture the scene from wide-angles to close-ups, in stills, time-lapses, and videos, including 4K. Details on the setup are in the caption for the video on Vimeo. Click through to Vimeo.

I scouted this site north of Driggs, Idaho two years earlier, in April 2015. It was perfect for me. I could easily set up lots of gear, it had a great sightline to the Grand Tetons, and a clear horizon for the twilight effects. And I had the site almost to myself. Observing with a crowd adds lots of energy and excitement, but also distraction and stress. I had five cameras to operate. It was an eclipse experience I’ll likely never duplicate.

If you missed this eclipse, you missed the event of a lifetime. Sorry. Plain and simple.

2017 Eclipse Time Sequence Composite
A composite of the 2017 eclipse with time running from left to right, depicting the onset of totality at left, then reappearance of the Sun at right. Taken with the 4-inch telescope shown above.
If you saw the eclipse, and want to see more, then over the next few years you will have to travel far and wide, mostly to the southern hemisphere between now and 2024.

But on April 8, 2024 the umbral shadow of the Moon once again sweeps across North America, bringing a generous four minutes of totality to a narrow path from Mexico, across the U.S., and up into eastern Canada.

It will be the Great North American Eclipse. Seven years to go!

— Alan, September 2, 2017 / © 2017 Alan Dyer / www.amazingsky.com



The Moons of Lost Sleep


Waning Moon in the Morning Series (with Labels)

These are the Moons only insomniacs and night shift workers get to see. These are the waning Moons of morning.

For eight mornings I’ve been up at 4 a.m. each day to catch the early Moon and collect a series of images of its waning phases.

The result is above, a series that runs from right to left in time, from the 19-day-old waning gibbous Moon, to the 26-day-old thin crescent Moon.

I ordered them that way in the composite to reflect the direction the Moon moves across the sky. As it orbits Earth and wanes, the Moon moves from west to east, or right to left, in the sky from morning to morning, at least in the northern hemisphere.

A run of clear nights and mornings made the series possible. From Alberta, as dry as it is, too many cloudy nights make a consistent Moon phase series a challenge at best.

As it was I had to contend with smoke from forest fires in B.C. which reddened the Moon on the last few mornings, a tint I had to correct for the composite above. But here below, is what the Moon really looked like one morning.

Smoky Waning Crescent Moon
The smoky orange Moon of July 17.

The last two Moons, at 25 and 26 days old (i.e. the number of days since the previous New Moon phase) exhibited the phenomenon known as Earthshine. You can see the night side of the Moon glowing gently with sunlight reflected first off the Earth.

Waning Moon and Earthshine (July 20, 2017)
Earthshine on the 25-day old Moon on July 20 at dawn.

Below, this was the Moon this morning, July 21, with it very low in the east amid the twilight sky.

Waning 26-Day Moon with Earthshine
Earthshine on the thin 26-day old Moon on July 21 at dawn.

This final morning was exceptional. The smoke had cleared off, and when I got up at 4 a.m. (reluctantly!) for the last shoot I was greeted with the best display of noctilucent clouds I had seen in many years. They covered the northeast and eastern skies in a rare “grand display.”

Noctilucent Clouds at Dawn with the Moon and Venus
Noctilucent clouds with the Moon and Venus in the dawn sky, from southern Alberta, July 21, 2017.

The thin crescent Moon is just rising at right, with Venus bright as a “morning star” at far right. This was a sky certainly worth losing sleep over.

— Alan, July 21, 2017 / © 2017 Alan Dyer / amazingsky.com



The Austral Moon of Evening


Waxing Moon in Evening Twilight Colours

From the southern hemisphere the Moon appears “upside-down” and higher each night in the northern sky as it waxes from crescent to Full.

These are scenes from the last week as the Moon rose higher into the evening sky as seen from Australia.

A northerner familiar with the sky would look at these and think these are images of the waning Moon at dawn in the eastern sky.

Waxing Crescent Moon at Cape Conran
The “upside-down” waxing crescent Moon in the evening sky from Victoria, Australia, at Cape Conran, West Cape area, on the Gippsland Coast, at latitude 37° South. Earthshine lights the dark side of the Moon. This was March 31, 2017. The Moon lights a glitter path on the water. This is a single 1.3-second exposure at f/2 with the 85mm Rokinon lens, and Canon 5D MkII at ISO 400.

But no, these are of the waxing Moon (the phases from New to Full) with the Moon in the evening sky.

From the southern hemisphere the ecliptic – the path of the planets – and the path of the Moon arcs across the northern sky. So as the Moon waxes from New to Full phase it appears to the right of the Sun, which still sets in the west. The world still spins the same way down under!

So the Moon appears upside down and with the crescent phase the “wrong” way for us northerners.

Panorama of the Waxing Moon at Sunset at Welshpool Harbour
A 240° panorama from 16 segments.

This panorama taken April 4 sweeps from northwest to southeast, but looks north at centre, to capture the scene at sunset of the waxing 8-day gibbous Moon in the northern sky as seen from the southern hemisphere.

The angle between the Sun and Moon is just over 90°, shown here by the angle between the right-angle arms of the wharf, pointed to the west at left, to the north at centre, and to the east at right.

The Sun has set just north of west, while the Moon sits 13° east of due north. The Earth’s shadow rises as the blue arc at far right to the east opposite the Sun.

Philip Island Sunset and Waxing Moon Panorama
A 240° panorama from 15 segments.

The next night, April 5, I shot this panorama from Philip Island south of Melbourne. Again, it shows the waxing gibbous Moon in the north far to the right of the setting Sun in the west (at left).

Getting used to the motion of the Sun and Moon across the northern sky, and the Moon appearing on the other side of the Sun than we are used to, is one of the challenges of getting to know the southern sky.

Things just don’t appear where nor move as you expect them to. But that’s one of the great delights of southern star gazing.

— Alan, April 8, 2017 / © 2017 Alan Dyer / www.amazingsky.com



How to Shoot the Solar Eclipse


Total Eclipse of the Sun Composite (2006 Libya)

The most spectacular sight the universe has to offer is coming to a sky near you this summer.

On August 21 the Moon will eclipse the Sun, totally!, along a path that crosses the continental USA from coast to coast. All the details of where to go are at the excellent website GreatAmericanEclipse.com

If this will be your first total solar eclipse, you might want to just watch it. But many will want to photograph or video it. It can be easy to do, or it can be very complex, for those who are after ambitious composites and time-lapses.

To tell you how to shoot the eclipse, with all types of cameras, from cell phones to DSLRs, with all types of techniques, from simple to advanced, I’ve prepared a comprehensive ebook, How to Photograph the Solar Eclipse.

eclipseebookcover

It is 295 pages of sage advice, gathered over 38 years of shooting 15 total solar eclipses around the world.

The book is filled with illustrations designed specifically for the 2017 eclipse – where the Sun will be, how to frame the scene, what will be in the sky, how the shadow will move, where the diamond rings will be, what lenses to use, etc.


Here are a few sample pages:

eclipseebook-1

I cover shooting with everything from wide-angle cameras for the entire scene, to close-ups with long telephotos and telescopes, both on tripods and on tracking mounts.


eclipseebook-5

I cover all the details on exposures and camera settings, and on focusing and ensuring the sharpest images. Most bad eclipse pix are ruined not by poor exposure but poor focus and blurry images – the Sun is moving!


eclipseebook-6

A big chapter covers processing of eclipse images, again, from simple images to complex stacks and composites.


Total Solar Eclipse C3 Diamond Ring and Totality (2012 Australia

For example, I show how to produce a shot like this, from 2012, combining a short diamond ring image with a long-exposure image of the corona.


chapter-10

A final chapter covers “what can go wrong!” and how to avoid the common mistakes.


For details on the ebook content, see my webpage for the book at http://www.amazingsky.com/eclipsebook.html

The ebook is available on the Apple iBooks Store for Mac and iOS devices. This version has the best interactivity (zoomable images), higher quality images (less compression), and easiest content navigation.

However, for non-Apple people and devices, the ebook can also be purchased directly from my website as a downloadable PDF, which has embedded hyperlinks to external sites.

I think you’ll find the ebook to be the most comprehensive guide to shooting solar eclipses you’ll find. It is up to date (as of last week!) and covers all the techniques for the digital age.

Many thanks, and clear skies on August 21, wherever you may be in the shadow of the Moon!

— Alan, February 28, 2017 / © 2017 Alan Dyer / amazingsky.com
